SDM-CD16AC 16 Channel AC/DC Controller
32: If Flag/Port (P91) If flag 2 is set
1: 12 Do if flag 2 is high
2: 30 Then Do Then
33: Beginning of Loop (P87)
Start fan loop
1: 0 Delay
2: 5 Loop Count
34: Z=F (P30)
PUT A "1" INTO FAN
1: 1 F CONTROL LOCATION
2: 0 Exponent of 10
3: 20-- Z Loc :
35: End (P95)
End fan loop
36: End (P95)
End then do
37: If time is (P92)
1: 0 minutes into a Reset flag 2 at the
2: 15 minute interval end of the 15 minute
3: 22 Set low Flag 2
END FAN CONTROL LOGIC BASED ON TIME
INPUT LOCATIONS 10 THROUGH 24 ARE NOW LOADED WITH "1" OR "0" TO SET
PORTS ON THE SDM-CD16AC.
38: SDM-CD16AC (P104)
Send instructions to the
1: 1 Reps SDM-CD16AC with address 00
2: 00 Address
3: 10 Loc
39: End Table 1 (P)
