Media Technology Systems STAGE 8.8 - Manual (Page 4)

Page 4 of 22 Oct‐12
Table of Contents
1 WELCOME 5
1.1 I MPORTANT S AFETY I NSTRUCTIONS 5
1.2 D ECLARATION OF C ONFORMITY : 5
1.3 H OW TO USE THIS MANUAL . 5
2 SPECIFICATIONS 6
3 FUNCTIONAL DESCRIPTION 7
3.1 S IGNAL P ATH 7
3.2 A NALOG S ECTION 7
3.3 D IGITAL SECTION 7
3.4 N ETWORK CONNECTIONS 9
3.5 P OWER S UPPLY 9
3.6 C ONNECTIONS 10
3.7 W ALL /F LOOR MOUNT KIT 10
4 SIMPLE CONFIGURATION (NO DSP) 12
4.1 CNDISCO ­ S ETUP 12
4.2 A DVANCED SETTINGS 13
4.3 C ONFIGURATION 14
4.4 P RESETS 17
4.5 S ETTING A STATIC IP ADDRESS 18
5 FIRMWARE 19
6 INDEX 22
