6
3
OPERATION
4
SPECIFICATIONS
The Remote Control is provided with 3 meter length of Cat 5 Networking Cable with 8P8C
(8 Position, 8 Conductor) Modular Plugs (RJ-45) on either ends . Plug one end of the cable
to the receptacle on the Remote Control.
Locate the 8P8C (8 Position, 8 Conductor) Modular Receptacle (RJ-45) on the inverter and
securely insert the other end of the plug on the Remote Control cable.
for switching on and switching off the Inverter using this Remote Control, the Main on /
off Switch on the Inverter should be in the off condition.
CAUTION! If the on / off Switch on the Inverter is left in on position, the Inverter
cannot be switched off using this Remote Control. The Remote Control will, however,
continue to display the status of operation.
Please see under “Layout and Operation of Controls and LED Indications” for display
information.
MODEL NO. SAM-RC
AppLICAbLE MODELS Of INvERTERS
SAM-1000-12, SAM-1500-12,
SAM-2000-12, SAM-3000-12
RECEpTACLE fOR CONNECTINg CAbLE
8P8C (8 Position, 8 Conductor)
Modular Receptacle (RJ-45)
CONNECTINg CAbLE TypE 8 Conductor, Cat 5 Networking Cable
CONNECTINg CAbLE, LENgTh 3 meters
CONNECTINg CAbLE, CONNECTORS
8P8C (8 Position, 8 Conductor)
Modular Plugs (RJ-45) on both ends
DIMENSIONS (wIThOUT CAbLE),MM (L
x
w
x
h) 115 x 70 x 27
DIMENSIONS (wIThOUT CAbLE), IN (L
x
w
x
h) 4.6 x 2.8 x 1.1
wEIghT (wIThOUT CAbLE), Kg 0.056
wEIghT (wIThOUT CAbLE), Lb 0.12
NOTE: Specifications are subject to change without notice
