4
2
GENERAL INFORMATION
NOTE: The White LeD backlighting will be on even when the Main on / off button on
the Inverter is in the off condition (Provided DC input voltage from the battery is
available at the DC input terminals of the Inverter).
3. Green LeD showing on / off status of the Remote Control. Remote is oN
when the LeD is lighted.
4.1 - 4.4 bar Graph consisting of 4 Green LeDs showing the battery voltage seen at
the DC input terminals of the Inverter as follows: (Voltages shown are for a
12 V Nominal battery input)
-LeD 4.1 is lighted battery voltage is 11.1 to 11.6 VDC
-LeD 4.1 and 4.2 are lighted: battery voltage is 11.6 to 12.8 VDC
-LeD 4.1, 4.2 and 4.3 are lighted: battery voltage is 12.8 to 13.2 VDC
-LeD 4.1, 4.2, 4.3 and 4.4 are lighted: battery voltage is 13.2 to 15.3 VDC
NOTE: The battery voltage seen at the DC input terminals of the Inverter will be lower
than the battery voltage at the battery terminal posts by the amount of voltage
drop along the length of the wires connecting the battery and the Inverter. It is
recommended that the voltage drop may be limited to 2% of the battery voltage by
ensuring that the thickness of the connecting wires is selected appropriately based
on the maximum current drawn by the Inverter from the battery and the distance
between the battery and the Inverter.
5.1 - 5.2 Green LeD (5.1) showing operation of the load controlled cooling fan.
-Lighted LeD (5.1) indicates that the power drawn by the load is less than 10%
of the rated power output of the Inverter and that the load controlled fan of
the Inverter is switched off to save power (The crossed out fan symbol (5.2)
indicates that the fan if off).
-extinguished LeD (5.1) indicates the load is more than 10% of the rated
output power of the Inverter and that the cooling fan inside the Inverter is on.
6.1 - 6.3 bar graph consisting of 3 Green LeD showing percentage of the rated
output power of the inverter being delivered to the load as follows:
-LeD 6.1 is lighted: Power drawn by the load is 10% to 59%
of the rated output power of the Inverter.
