LK162-12 rev 4 32
8. Appendix: Specifications and Options
8.1 Specifications
Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature 0°C to +50°C -20°C to +70°C
Storage Temperature -20°C to +70°C -40°C to +85°C
Operating Relative Humidity 90% max non-condensing 90% max non-condensing
Electrical Specifications
Supply Voltage 4.75 - 5.25 Vdc (optional 7 – 15 Vdc)
Supply Current 9 mA typical
Supply Backlight Current 115 mA typical
Optical Characteristics
Number of Characters 32 (16 characters by 2 lines)
Matrix format 5 x 7 with underline
Display Area 62.5 x 16.10 mm XxY
Character Size
3.20 x 5.55 mm (XxY), not including
underline
Character Pitch 3.7 mm
Line pitch 6.09 mm
Dot Size 0.50 x 0.55 mm (XxY)
Dot Pitch 0.57 x 0.62 mm (XxY)
LED Backlight Life 100,000 hours typical
Color of Illumination Yellow Green
