76
INDEX NAME
DATA
TYPE
NOTES
104 FlowTbl[8].FlowPFS float Flow Linearizer Index 8 PFS [0.0 – 1.0]
105 FlowTbl[8].LinCounts uint Flow Linearizer Index 8 Counts
106 FlowTbl[9].FlowPFS float Flow Linearizer Index 9 PFS [0.0 – 1.0]
107 FlowTbl[9].LinCounts uint Flow Linearizer Index 9 Counts
108 FlowTbl[10].FlowPFS float Flow Linearizer Index 10 PFS [0.0 – 1.0]
109 FlowTbl[10].LinCounts uint Flow Linearizer Index 10 Counts
110 PulseMeasInt uint Flow Pulse Measure Interval in mS [500-60000]
111 FlowMeasureMode uint Flow measure mode [0-4]
112 Flow_NRF_NSample uint Flow NRF Number of Samples [1-32] for PWM
113 Flow_NRF_ErrLimit float Flow NRF Error Value [0.05 10.0]%F.S. for PWM
114 Flow_NRF_TimeLimit uint Flow NRF Time Interval for PWM [0-199], 0-dis'd
115 Flow_Damping uint Reading Damping 1-99 (sec.) for PC mode
116 Flow_Window uint Flow running average window for PC mode [0-100], 0-dis'd
117 FlowAWD_NRF_NSample uint Flow NRF Number of Samples [1-32] for AWD
118 FlowAWD_NRF_ErrLimit float Flow NRF Error Value [0.05 10.0]%F.S. for AWD
119 FlowAWD_NRF_TimeLimit uint Flow NRF Time Interval for AWD [0-199], 0-dis'd
120 Min_Freq_PWM uint Minimum measure Frequency for PWM model
121 Max_Freq_PWM uint Maximum measure Frequency for PWM model
122 Min_Freq_AWD uint Minimum measure Frequency for AWD model
123 Max_Freq_AWD uint Maximum measure Frequency for AWD mode
124 AWD_DC_Offset uint AWD DC offset for AWD mode (def. 2225 counts)
125 AWD_Tresh_PFS uint AWD threshold in % of Average DC offset for AWD mode (1 - 80)
126 FFT_DSP_Enable uint FFT algorithm Enable/Disable
127 FFT_Sample_Rate uint
FFT Sample Frequency: 0-Auto,1 - 8000, 2 - 4000, 3 - 2000,
4 - 1000, 5 - 500Hz
128 FFT_Triger_Level uint FFT Trigger level counts (0-4095)
129 FFT_NoiseTreshold float FFT Noise threshold counts (0-4000)
130 DP_Channel_1 uint Sensor#1 DP master attenuator setting (original)
131 DP_Channel_2 uint Sensor#2 DP master attenuator setting (original)
132 Auto_Att_Mode uint Signal Auto Attenuation Mode: 0-Dis'd, 1-Enb'd
133 Auto_Att_Target_Level float Signal Auto Attenuation Target level (RMS counts)
134 Meter_Pipe_ID float Meter or Pipe Internal Diameter (inch)
135 Meter_FS_Range float Meter Full Scale range in L/min
136 MeterCalFactor float Calibration Factor:[Hz/l/min] (for STD conditions)
137 Vortex_Coeff_Ck float Manuf. Specific settings (do not change)
138 LowFlowCutOff float Meter low flow cut off [0 - 25.0 %F.S.]
139 Low_Freq_CutOff float Meter Low Frequency cut off (Hz)
140 High_Freq_CutOff float Meter High Frequency cut off (Hz)
