Aalborg GFM User Manual
Page 32
28
APPENDIX 3
DIMENSIONAL DRAWINGS
FLOW
2.38
0.95
F
G
6-32
H
A
B
C
C
*
*
*
E
D
E
D
NO LCD
VERSION
DASHED LINE FOR
HIGH FLOW UNITS
NOTES: Aalborg
7 reserves the right to change designs and dimensions at its sole discretion at any
time without notice. For certified dimensions please contact Aalborg
7.
MODEL
CONNECTION
Compression Fitting
(except model GFM 77)
DIMENSION (INCH)
LCD VERSION
NO
LCD
A
B
C/*C
D/*D
E/*E
F
G
H
GFM 17
1/4" Tube O Diameter
5.60
1.00
1.00
3.00
5.02
0.69
2.69
4.50
GFM 37
1/4" Tube O Diameter
5.98
1.37
1.25
4.13
6.15
0.69
2.69
4.88
GFM 47 3/8" Tube O Diameter
5.98
1.37
1.25
4.13
6.27
0.69
2.69
4.88
GFM 57 3/8" Tube O Diameter
6.60
2.00
1.75
6.69
8.83
0.99
4.69
5.50
GFM 67
1/2" Tube O Diameter
7.60
3.00
3.00
7.25
9.67
2.250
6.750
6.50
GFM 77
3/4" NPT Female
8.60
4.00
4.00
7.30
-
3.000
6.800
7.50
