Legacy Classic Furniture Door Dresser 490-1000C - Manual

Assembly Instructions for Bun Feet
Step 1. Unpack carton and inventory parts.
Step 2. Open drawers and locate box packed inside containing Bun Feet.
Step 3. Turn unit on its back in order to access bottom. Insert DOWELS (4) into non-threaded holes on the
bottom of the unit and attach BUN FEET to the bottom of the unit use BOLT (3), SPRING
WASHER (2), FLAT WASHER (1), and tighten it with SCREWDRIVER. (Not Included)
Step 4. Turn unit upright carefully.
Note: During normal use everyday, bolts and nuts may loosen up. They should be periodically inspected and
re-tightened to prevent damage to the furniture and (or) personal property or cause injury. Always check to
be sure all hardware on this list is attached to the furniture properly and kept tightened at all times.
3
Step 3
5
4
1
2
5/16" BOLT 4PCS
40mm DOWEL 8PCS
5/16"
5/16"
FLAT WASHER
SPRING WASHER
4PCS
4PCS
3
4 2
1
--The End--
