• Separate slide parts. (See drawer removal instructions.)
Gu
Gd
Gd(8)
CC
J(4)
KK
Release
• Attach (2) drawer slides (Gd) to each drawer (J) as shown.
• Wrench tighten.
CC(16)
KK(16)
STEP 4:
• Attach (2) E using (8) AA, (8) GG and (8) JJ.
• Finger tighten. (Do not wrench tighten until step 6.)
E(2)
AA
GG
JJ
AA(8)
GG(8)
JJ(8)
STEP 3:
