The ECONOMITE Models 400B-02 and 400B-02P conversion burners are adaptable to most common central gas utilization
equipment, including up-draft gravity and forced circulation furnaces and boilers. Power burner design makes it perfectly suited
for oil burner replacement. For horizontal and downdraft gas utilization equipment, ECONOMITE Model DS45B conversion burn-
er with direct spark ignition is recommended.
In the United States, installation must conform with local
codes or, in the absence of local codes, with Installation
of Domestic Gas Conversion Burners, ANSI Z21.8a-
latest edition and National Fuel Gas Code, ANSI
Z223.1-latest edition(s) available from American
National Standard Institute. Further reference should
be made to the recommendation of your fuel supplier.
Note: Any additions, changes or conversions required in
order for the gas utilization equipment to satisfactorily
meet the application needs must be made by a MIDCO dis
tributor (or other qualified agency) using factory specified
and approved parts.
In Canada, installation must conform with local codes or, in
the absence of local codes, with Installation Codes for
Gas Burning Appliances and Equipment, CGA
Standard CAN/CGA 1-B149.1 or 2. When the conver-
sion burner is used on Forced Air Central Furnace, the
two yellow and black warning labels in the literature enve
lope shall be at tached in accordance with Installation
Code, CGA Standard CAN /CGA 1-B149,Clause 5.4.4.4.
Further reference should be made to the recommendation
of your fuel supplier.
INSTALLER: Inform and demonstrate to the user
the correct operation and maintenance of this gas
utilization equipment. Inform the user of the haz-
ards of storing flammable liquids and vapors in
the vicinity of this gas utilization equipment and
remove such hazards. Affix this manual adjacent
to the conversion burner.
CODE COMPLIANCE IS THE SOLE RESPONSIBILITY
OF THE INSTALLER.
WARNING: If the information in
these instructions is not followed
exactly, a fire or explosion may result,
causing property damage, personal
injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
Installation and service must be per-
formed by a qualified installer, service
agency or the gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical
switch; do not use any phone in
your building.
• Immediately call your gas
supplier from a neighbor's
phone. Follow the gas suppliers'
instructions.
• If you cannot reach your gas
supplier, call the fire department.
USER: Retain this manual for future reference. If other than routine service or maintenance
as described in this manual is required, contact a qualified service agency. DO NOT
ATTEMPT REPAIRS. An inadvertent service error could result in a dangerous condition.
SAFETY INFORMATION TERMS : The following terms are used to identify hazards, safety precautions or special nota-
tions and have standard meanings throughout this manual. When you see the safety alert symbol and one of the safety
information terms as shown below, be aware of the hazard potential.
DANGER: Identifies the most serious hazards which will result in severe personal injury or death.
WARNING: Signifies a hazard that could result in personal injury or death.
CAUTION: Identifies unsafe practices which would result in minor personal injury or product and property damage.
ANSI Z21.17$CSA 2.7
CONVERSION BURNERS
Installation and Service Instructions
M i d c o I n t e r n a t i o n a l I n c .
4140 West Victoria Street Chicago, Illinois 60646
tel 773.604.8700 fax 773.604.4070 web www.midco-intl.com 201
8470-75
Printed in U.S.A.
Economite 400B-02
Conversion Burners
