Section 2. Installation
7
CONNECTORS
Head connections for the three models are shown in the tables below.
Table 2-1. Head Connections for Track 2
Signal Color
HEAD CASE GND Black
READ HEAD TRACK 2 White
Wires Only -
No Connector
READ HEAD TRACK 2 Red
Table 2-2. Head Connections for Tracks 1 and 2
Pin Number Signal Color
1 HEAD CASE (GND) Black
2 READ HEAD TK 1 White
3 READ HEAD TK 1 Yellow
4 READ HEAD TK 2 Red
Connector for Dual Track, 5 Pin
Molex 51021-0500
1.25 mm Contact Spacing
Mates with Headers 53398-0590,
53261-0590, 53047-0510, 53048-0510
5 READ HEAD TK 2 Green
Table 2-3. Head Connections for Tracks 1, 2 and 3
Pin Number Signal Color
1 HEAD CASE (GND) Black
2 READ HEAD TK 1 Red
3 READ HEAD TK 1 Red
4 READ HEAD TK 2 Green
5 READ HEAD TK 2 Green
6 READ HEAD TK 3 Yellow
Connector for Dual Track, 7 Pin
Molex 51021-0700
1.25 mm Contact Spacing
Mates with Headers 53398-0790,
53261-0790, 53047-0710, 53048-0710
7 READ HEAD TK 3 Yellow
