Swipe Readers with RS-232 IntelliHead
2
SPECIFICATIONS
Table 1-2. Specifications
OPERATING
Card Data Formats ISO/ANSI/AAMVA*
Data Transmission EIT/TIA-232 and V.28/V.24 compatible or compliant (see below) for TXD line
Recording Method Two-frequency coherent phase (F2F)
Message Format ASCII
Card Speed 3 to 60 in/s (7.6 to 152.4 cm/s)
ELECTRICAL
Power Input† From RS-232 interface port (Host-referenced DTR and TXD signals)
DTR (Host-referenced)
or external positive
supply +4.9 VDC at 5 mA** to +16.0 VDC recommended operating range for
EIT/TIA-232 and V.28/V.24 compatibility
+5.1 VDC at 5 mA** to +16.0 VDC recommended operating range for full
EIT/TIA-232 and V.28/V.24 compliance with the exception of the absolute
maximum ratings***
TXD (Host-referenced)
or external negative
supply
-4.1 VDC at 1.9 mA to -16.0 VDC recommended operating range for
EIT/TIA-232 and V.28/V.24 compatibility
-5.1 VDC at 2.2 mA to -16.0 VDC recommended operating range for full
EIT/TIA-232 and V.28/V.24 compliance with the exception of the absolute
maximum ratings***
RS-232 Communication 9600 bps, 8 data bits, no parity, 1 stop bit
MECHANICAL (STANDARD PRODUCT)
Dimensions See related appendix
Cable Length See related appendix
Connector See related appendix
Life 1,000,000 passes
ENVIRONMENTAL
Temperature
Operating:
Storage:
-40 o C to +70 o C (-40 o F to +158 o F)
-40 o C to +70 o C (-40 o F to +158 o F)
Humidity
Operating:
Storage:
10% to 90% noncondensing
10% to 90% noncondensing
* ISO (International Standards Organization), ANSI (American National Standards Institute), and
AAMVA (American Association of Motor Vehicle Administrators)
** 8 mA for units manufactured prior to May 2006.
*** Absolute maximum ratings are ±20 VDC for the DTR line, and +20, -25 VDC for the TXD line. Full
EIT/TIA-232 and V.28/V.24 compliance requires that these lines withstand ±25 VDC. Absolute
maximum ratings for units manufactured prior to May 2006 are ±16 VDC for the DTR line, and +16,
-25 VDC for the TXD line.
† A note about “port-powered” readers –These readers operate off some combination of otherwise
unused RS-232 lines, DTR and TXD in this case. Per the RS-232 specification, these lines are
