90-millimeter Compatible Swipe Reader
4
CONNECTORS
Single Track I/O Connector is shown in Table 2-1, and the Dual Track I/O Connector is shown
in Table 2-2.
Table 2-1. I/O Connector for Single Track, 5 Pin
Pin Number Color Signal
Connector for Single Track, 5 Pin 1 Red V
cc
Molex 5 Pin 2 Black GND
22-01-2051 3 Orange DATA
0.100 inch Contact Spacing 4 Brown STROBE
Mates to Molex 22-05-2051 5 Green CARD PRESENT
Note: V
cc
= 2.7 to 5.5 VDC
Table 2-2. I/O Connector for Dual Track, 7 Pin
Pin Number Color Signal
Connector for Dual Track, 7 Pin 1 Red V
cc
2 Black GND
3 Orange DATA (Tk 2)
Molex 7 Pin 4 Brown STROBE (Tk 2)
22-01-2071 5 Green CARD PRESENT
0.100 inch Contact Spacing 6 Yellow STROBE (Tk 1)
Mates to Molex 22-05-2071 7 White DATA (Tk 1)
Note: V
cc
= 2.7 to 5.5 VDC
