1
SECTION 1. FEATURES AND SPECIFICATIONS
The 100-millimeter OEM Swipe Reader has a TTL level interface and is designed for use in
retail, access control, and time and attendance environments. This Reader is in compliance with
industry specifications, including ANSI/ISO Standards 7810, 7811-1 through -6, 7812, 7813, and
AAMVA. The Reader can be customized. Bidirectional read capability is available.
CONFIGURATIONS
Part Number Read Color Cable Length
Integral Electronics,
Single Track with Cover 21040004
21040005 Track 1
Track 2 Black
Black 12”
12”
Integral Electronics,
Single Track without Cover 21040001
21040003 Track 1
Track 2 Black
Black 12”
12”
Integral Electronics,
Dual Tracks without Cover
Dual Tracks with Cover
21040026
21040047
Tracks 1 & 2
Tracks 1 & 2
Black
Black
21”
21”
Integral Electronics,
3 Tracks with Cover 21040057 Tracks 1,2, & 3 Black 20”
SPECIFICATIONS
IEC:
Meets or Exceeds
Requirements for: IEC 1000-4-2 ESD (Electro Static Discharge)
IEC 1000-4-3 Radiated EMC Field (2X requirement)
IEC 1000-4-4 Electrical Fast Transient Burst requirement
(transmission on I/O cable)
Flammability Meets UL94V-0
Recording Method Two-Frequency Coherent Phase (F2F)
Speed
Card speed through the unit may vary from:
2 to 125 in/s at 75 bpi (5.1 to 318 cm/s at 29.5 b/cm)
2 to 60 in/s at 210 bpi (5.1 to 152.4 cm/s at 82.7b/cm)
Power Requirements Single Track: 2.7 to 5.5VDC at 1mA, typical
Dual Track: 2.7 to 5.5VDC at 2mA, typical
3 Tracks: 2.7 to 5.5VDC at 3mA, typical
Output Signal Levels V
ol
= 0.4V at 2mA
V
oh
= V
cc
-0.5V at -2mA
Operating Temperature -30
o
C to 70
o
C
Operating Humidity 10% to 90% relative humidity
Life 300,000 passes Single Track
1,000,000 passes Multi-Track
MTBF Electronics 125,000 h
Dimensions Length: 3.94" (100 mm)
Height: 1.23" (31.3mm)
Width: 1.28"
(32.5mm)
Cable Length: Single Track: 12" (305mm)
Dual Track: 21" (533mm)
3 Track 20" (508.0mm)
Connector See Section 2, Connectors
Colors available Black, Standard
Pearl White Available
