1
SECTION 1. FEATURES AND SPECIFICATIONS
The Swipe Readers presented in this manual are designed for reading capabilities for use in
retail, access control, time and attendance, and other applications.
The Reader chassis provide an industry standard mechanical footprint, along with magstripe read
capabilities, which comply with ISO 7810 and AAMVA standards. The Shift-Out IntelliHead
TM
interface provides a next generation electronics interface, which simplifies the process of
collecting data bits as the card is swiped.
• Low power and “sleep mode” capabilities, which make these products ideal for use in
hand-held battery-powered devices
• Low voltage operation. (Models are available in 5V (2.8 VDC - 5.5 VDC) or 3V (2.7
VDC – 3.6 VDC) versions)
• Automatic detection of card swipe and real-time data collection
• Shift-Out IntelliHead data interface. (See Reference Documents for more
information.)
MODELS
The models currently offered are as follows:
Part Number Transition
Revision*
Description Tracks Cable Length Drawing In
21040126 B 3V 100mm 1, 2, 3 1800mm (6 ft) Appendix A
21040129 B 3V 100mm 1, 2, 3 127mm (5 in) Appendix B
21040149 N/A 5V 100mm 1, 2, 3 127mm (5 in) Appendix B
21044007 B 3V 43mm 1, 2, 3 90mm (3.5 in) Appendix C
21045084 D 3V 90mm 1, 2, 3 80mm (3.1 in) Appendix D
21045091 N/A 5V 90mm 1, 2, 3 80mm (3.1 in) Appendix E
21046002 B 3V 60mm Slim Profile 1, 2, 3 125mm (4.9 in) Appendix F
21047008 C 3V 90mm Slim Profile 1, 2, 3 125mm (4.9 in) Appendix G
21047019 N/A 5V 90mm Slim Profile 1, 2, 3 125mm (4.9 in) Appendix H
* The “Transition Revision” represents the first Revision for which the “3V” Delta ASIC (21006540/41)
was used instead of the older “5V” Delta ASIC. The “5V” Delta ASIC (21006529/39 or 21006536/37) is
detailed in 99875336 or 99875259. N/A indicates that this part number was introduced with a 5V part.
