Burr King Model 85 User Manual
Page 16
USE FOR DRY OPPERATIONS.
3379 PLUG 3/4 PUC 1
M85
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
1
3311-2
MAIN FRAME
1
2
3314
FOOT, MACHINE
6
3
3312
ISOLATOR 45 SHORE
8
4
5-0023
WASHER, 3/8 X 7/8, USS
12
5
4-0007
NUT, 3/8-16, ELASTIC LOCK GD 2
8
6
3300UCI-3
TUB, URETHANE
1
7
5-0014
WASHER, LOCK 3/8, INTERNAL STAR
8
8
3318
CLAMP, HOSE 3" TO 5" SCREW DRIVE
1
9
3307
PLUG, URETH. CHUTE SEAL
1
10
3598
O-RING
1
11
3599
PLUG, DRAIN, MEDIUM
1
12
15
WASHER, 5/16 LOCK, SPLIT
5
13
9
SCREW, 10-24x1/2 BH, BLK OXIDE
5
14
3404
FITTING, BARBED, 3/4 NPT, NYLON
1
15
3406
CLAMP
1
16
3409
HOSE, 5/8
2
17
3317
PAIL, 5 GALLON
1
18
3348
BRACE, TUBE
1
19
31-1
1/4-20 x 1 1/2 FH SOC
2
20
3344-1
FITTING, CAP - 1/4NPT, FEMALE
1
21
3349
PIPE, 3/8 GALV.
1
22
3320-1
CLIP, RETAINER
1
23
2-0015
SCREW, 5/16-24x3/8 BH, BLK OX
1
M85
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
24
3338
ELBOW, 1/4 NPT, GALV
1
25
3378
BUSHING, 3/8x1/4 GALV.
1
26
3337
VALVE, BALL, 1/4 NPT
1
27
3339
FITTING, BARBED HOSE, 1/4 NPT
1
28
3336
HOSE, 1/4
1
29
3340
BARB
1
30
3316-3
PUMP
1
31
3331
BRACKET, PUMP
1
32
2-0014
SCREW, 1/4-20x1/2 BH, BLK OX
18
33
1-0005
BOLT, 3/8-16 x 3/4, HEX
4
34
MOTOR
CALL FACTORY OF MOTOR
1
35
1-0015
BOLT, 5/16-18x1 1/2 HEX HEAD
4
36
4-0014
NUT, 3/8-16, ELASTIC LOCK GD 2
4
37
3343
PULLEY 3.35 DIA
1
38
3310
BEARING, PILLOW BLOCK
4
39
3303-1
SHAFT, DRIVE
1
40
3305-1
WEIGHT, THROW
6
41
3-0001
SCREW, 3/8-16x1/2 SET
6
42
3342
PULLEY, 5.75 DIA
1
43
1-0008
BOLT, 1/2-13x1 1/2 HEX HEAD
8
44
5-0007
WASHER, 1/2 LOCK EXT
8
45
21
WASHER, 1/2 ID
8
46
3309-3
BELT, V
1
TITLE
DATE DRAWN REV DATE DRAWN BY SHEET
M25/ M45/ M85
8/19/2009
CMW
4 OF 4
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
