NOTE
TO USE 944 MUST HAVE 907K IDLER WHEEL.
USE TO ATTACH WORKREST TO 944
OPTIONAL ATTACHMENTS
944
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 9066 ARM, MAIN ATTACHMENT 1
2 25 SCREW, SET, 5/16-18 X 3/8, ALLEN 1
3 5 WASHER, 1/4 AN 6
4 31 SCREW 1/4-20x1 1/4 SHCS 4
5 904B-5 BRACKET, PLATEN 1
6 904AKM PLATEN 1
7 30 SCREW 1/4-20x1 SHCS 2
8 1444A SHAFT, IDLER 1
9 202B BEARING 2
10 202K WHEEL, CONTACT 2x2 w/Brg. & Shaft 1
11 1454 RING, RETAINING, E STYLE 1
12 402 CONTACT WHL, 5x2 1
946K
ITEM NO. PART
NUMBER
DESCRIPTION QTY.
13 946KM ARM 1
14 5 WASHER, 1/4 AN 3
15 2-0062 SCREW, 1/4-20 X 1.5 ALLEN 3
1276 & 1277
ITEM NO. PART
NUMBER
DESCRIPTION QTY.
16 1276B ARM, UNI 1x1 1
17 1277B ARM, FORK 1x2 1
18 31 SCREW1/4-20x1 1/4 SHCS 2
19 5-0008 WASHER, 1/4, LOCK, EXTERNAL 2
20 1277A STUD 2
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
