Burr King Model 960-401 - Manual (Page 17)

* USES A 011D TOGGLE SWITCH
945-4S
ITEM NO. PART NUMBER DESCRIPTION QTY.
80 737A KNOB, HANDLE 1
81 737B-1 BUTTON 1
82 26 PIN, 3/32 x 3/8, ROLL PLTED 1
83 737D SPRING, REAR WHEEL ASSY 1
84 737E NIPPLE, HANDLE 1
85 940 SUPPORT, IDLER WHEEL 1
86 27 SCREW, #8 X 5/8, DRIVE 1
87 937BA STRIP, BUTTON ASSEMBLY 1
88 28 SCREW, #2 x 1/4, DRIVE 1
89 737F PAWL 1
90 5-0027 WASHER, #8,18-8 STAINLESS STEEL 1
91 937G HANDLE 1
92 34 SCREW, 1/4-20 X 1, FH PHILLIPS 1
93 989 SPRING, BELT TENSION 1
94 939 GUIDE, SPRING 1
95 736 SECTOR 1
96 15 WASHER, #10, LOCK 2
97 3 NUT, 1/4-20 JAM, PLTD 2
98 25 SCREW, 5/16-18 x 3/8, SET, SOC 1
99 935 SUPPORT, REAR WHEEL 1
100 21 WASHER, 1/2 SAE, FLAT, ZINC 1
101 20 NUT, 1/2-20, JAM, ESNA, NTE 1
TITLE DATE DRAWN REV DATE DRAWN BY SHEET
M960-401 9/25/2009 CMW 3 OF 6
M960-401
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 4 WASHER, 5/16 SAE ZINC PLTD 10
2 MOTOR CALL FACTORY 1
3 37 BOLT, 5/16-18x3/4 HH, GRD5, PLTD 4
4 921-4 KNOB, TRACKING ASSY 1
5 922 LOCK, KNOB, TRACKING 1
6 18 WASHER, 960-516, AN 1
7 2-0023 SCREW, 10-24 X 5/8 SC ALLEN 3
8 5-0035 WASHER, #10, LOCK, HIGH COLLAR 3
9 17 WASHER, 960-616, AN 6
10 1-0003 BOLT, 3/8-16 x 1 1/4 HEX HEAD 2
11 941 BASE 1
12 31 SCREW, 1/4-20x1 1/4 SOC CAP 7
13 5 WASHER, 960-416, AN 12
14 42 WASHER, 3/8,THRU-HARD, YZ 4
15 5-0014 WASHER, 3/8, LOCK, INTERNAL STAR 2
16 908 ADAPTER, C-FACE MOTOR 1
17 920 STUD 3/8"x1 1/2", DOUBLE 4
18 923-4 BRACKET, TRACKING 1
19 900-4 FRAME/GUARD, ASSEMBLY 1
20 725 PULLEY, 2 1/2" 1
21 429K BELT, V, NOTCHED, 4L240 1
22 6 SCREW, 1/4-20 x 1 1/2 FH ALLEN 3
23 701 BEARING, CONTACT WHEEL ASSY 1
24 705-1 ARM, WORKREST SUPPORT 1
25 39 NUT, 3/8-24, JAM, ESNA, NTE 4
26 40 WASHER, 3/8, SAE, PLTD 1
27 730 PULLEY, 3" 1
28 6-0014 PIN, 1/8 X 3/4, ROLL 1
29 706-1 WORKREST, ANTI-TILT 1
30 3569 ELBOW, STREET, EXTRUD, 1/8NP 2
31 3571 BLOCK, SECURING 1
32 1-0035 BOLT, 1/4-20 x 1.25, SOC CAP SS 2
33 3570 TEE, BRASS, EXTRUDE, 1/8NPTF 1
34 3572 BARB, 1/8MP TO 1/4 TUBE, BRASS 1
35 3568 NOZZLE, SPRAY, BRASS, V8NPT 2
36 3577-3 BRACKET, BRUSH RETAINING 1
37 3-0026 SCREW, 8-32 x 1, FLATHEAD, PHILLPS, SS 3
38 3577 FELT 1
39 1-0019 BOLT, 5/16-18x1 1/2 HH, CS, ZN PLTD 6
40 904A PLATEN, BACKUP 1
41 30 SCREW, 1/4-20x1 SHCS 5
42 209 SCREW, 1/4-20 X 3/4 SHCS 1
43 4-0013 NUT, 1/4-20, KEP 2
44 5-0032 WASHER, 1/4, LOCK, SPLIT, PLTD 1
45 924 SUPPORT, BACKUP 1
46 4-0009 NUT, 5/16-18, JAM, PLTD 1
47 1 BOLT, 5/16-18x1, HH, GRD 5, PLTD 1
48 2-0011 SCREW, 1/4-20 X 1.5 SOC CAP 3
49 3-0039 SCREW, 1/4-20 x 3/4, S/S FH SCS 3
50 904B BRACKET, PLATEN 1
51 942-4S GUARD, SAFETY, PAINTED 1
52 3408 TUBING, CLEAR, FLEXIBLE, 1/4ID 1
53 3578 CLAMP,3/8OD, PLS. HOSE 2
54 3-0036 SCREW, 10-32 X 1 1/4 ALLEN CAP 2
55 3340 BARB, HOSE, FM, 1/4H x 1/4F 1
56 707c SHAFT, BEARING 1
57 701F RING, RETAINING, 5/8 EXTERNAL 2
M960-401
ITEM NO. PART NUMBER DESCRIPTION QTY.
58 701B BEARING 2
59 907 WHEEL, IDLER 1
60 4-0025 NUT, 8-32, ELASTIC, STOP, SS 5
61 23 NUT, 6-32, KEP, PLTD 3
62 903 GUARD, CONTACT WHEEL 1
63 4-0022 NUT, 1/2-20, NYLOK, SS 5
64 942C-4 STANDOFF, DOOR 1
65 742L1 LATCH, STUD, CLEAR ZN PLTD 1
66 3406 CLAMP, HOSE, 7/16" TO 1" 1
67 DF4-1 SCOOP, FLUID, SS 1
68 942B-1 DOOR, GUARD 1
69 3409 HOSE, STL. REINF., 5/8ID VIN 1
70 802 CONTACT WHEEL, 7x2.5, 55 DURO 1
71 726 FLANGE, OUTER WHEEL 1
72 727 NUT, 5/8-18 RH, JAM, BRT PLT 1
73 3337 VALVE, LOW PRESSURE, 1/4 NPT 1
74 3339 BARB, ML, HOSE, 1/4H x 1/4M 1
75 742E HINGE, GUARD TO DOOR 1
76 14 NUT, 10-24, KEP 3
77 24 SCREW, 6-32 x 1/2, MACH 3
78 742H GROMMET, SAFETY GUARD DOOR 1
79 9 SCREW, 10-24x1/2 BH, BLK OXIDE 3
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
