Burr King Model 760 - Manual (Page 12)

1220 TAMARA LANE
BURR KING
WARSAW, MO. 65355
54 SCREW, 10-24x1/2 BH, BLK OXIDE 9
PARTS LIST
MAIN BODY LIST ITEM 39 LIST - 745 ITEM 32 LIST - 712
MODEL 760
55 739 GUIDE, SPRING
56 738 SPRING, BELT TENSION
57 737G ARM, TENSION
58 737F PAWL
59 737C STRIP, HANDLE
60 737A KNOB, REAR TENSION ARM
61 737B-1 BUTTON
62 27 SCREW, DRIVE, #8 X 5/8
63 28 SCREW, DRIVE, #2 x 1/4
64 737E NIPPLE, PIPE
65 26 PIN, 3/32 x 3/8, ROLL PLTED
66 737D SPRING, BUTTON
26 MOTOR MOTOR, 1 1/2HP, 120/220V/1PH/C-FACE
27 730 PULLEY, 3
28 729 BELT, V DRIVE
29 2 BOLT, 5/16-18x1 1/2 HEX HEAD
30 742A-1 GUARD, SAFETY
31 8 SCREW, 10-24 x 1-1/2, BUTTON
32 712 TRACKING ASSY, UPPER IDLER
33 707c SHAFT, BEARING
34 701B BEARING 5/8 x 1 3/8
35 707EX WHEEL, IDLER
36 1-0037 BOLT, 3/8-16 x 1-1/4, CARRAGE
37 4-0005 NUT, 3/8-16, JAM, ELASTIC, PLTD
38 711 KNOB ASSY, TRACKING
39 745 BELT TENSIONING ASSEMBLY
40 7 SCREW, 10-24 x 1 1/2 FLAT HD
41 14 NUT, 10-24, KEP
42 701F WHEEL, IDLER CIR-CLIP
43 742B-1 DOOR, SAFETY GUARD
44 742H GROMMET, SAFETY GUARD DOOR
45 742L LATCH, SAFETY GUARD DOOR
46 338-2 SPRING, TRACKING
ITEM # PART # DESCRIPTION
1 700 FRAME, MAIN
2 731 BASE, MACHINE
3 4 WASHER, 5/16 SAE ZINC PLTD
4 1 BOLT, 5/16-18x1, HH, GRD 5, PLTD
5 701 BEARING, CONTACT WHEEL ASSY
6 6 1/4-20 x 1 1/2 FH SOC
7 702 WHEEL, CONTACT
8 703-3 GUARD, CONTACT WHEEL
9 30 1/4-20x1 SHCS
10 5 WASHER, 1/4 AN
11 704B BRACKET, PLATEN
12 209 SCREW, 1/4-20 X 3/4 ALLEN HEAD
13 704A PLATEN
14 15 WASHER, 5/16 LOCK, SPLIT
15 13 SCREW, 10-24 x 3/4, SOC, HD, CAP
16 705-1 ARM, WORKREST SUPPORT
17 706-1 WORKREST, ANTI-TILT
18 31 1/4-20x1 1/4 SHCS
19 6-0014 PIN, 1/8 X 3/4, ROLL PLTED
20 726 WASHER, SPRING FLANGE
21 727 NUT, 5/8-18 RH, JAM, BRT PLT
22 728A STANDOFF, GUARD
23 728 GUARD, V-BELT, INVERT
24 3 NUT, 1/4-20 JAM, PLTD
25 725 PULLEY, 2 1/2
ITEM # PART # DESCRIPTION
47 734 BASE PLATE
48 735 SUPPORT. REAR WHL
49 25 SCREW, SET, 5/16-18 X 3/8, ALLEN
50 736 RACHET
51 34 SCREW, 1/4-20 X 1, FH PHILLIPS
52 20 NUT, NYLOK JAM, 1/2-20
53 21 WASHER, 1/2 ID
ITEM # PART # DESCRIPTION
67 710 BRACKET, PIVOT BLOCK
68 714-1 BODY, TRACKING
69 25 SCREW, SET, 5/16-18 X 3/8, ALLEN
70 716 PIVOT BLOCK MOUNT
71 717 BLOCK, PIVOT
72 16 WASHER, 960-716, AN
73 18 WASHER, 960-516, AN
74 29 SCREW, 10-32 X 1/2 BH
75 19 NUT, 5/16-24, ESNA
76 724 PIN, ROLL, 1/4 x 1
77 5-0035 WASHER, #10, LOCK, HIGH COLLAR
78 13 SCREW, 10-24 x 3/4, SOC, HD, CAP
