Page 13
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
TITLE
DATE
DRAWN
REV
DATE
DRAWN
BY
SHEET
M960-400 04/01/11 04/08/11
SRM
2 OF 2
M960-400
945-4
M960-400
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
1
941
BASE
1
2
MOTOR
CALL FACTORY
1
3
908
ADAPTER, C-FACE MOTOR
1
4
900-4A
FRAME, GUARD
1
5
920
STUD 3/8"x1 1/2", DOUBLE
4
6
933
PULLEY, USES 947 BUSHING
2
7
701
SHAFT, BEARING
1
8
947
BUSHING
2
9
905-4
ARM, WORKREST SUPPORT
1
10
906-4
WORKREST, ANTITILT
1
11
903-4
GUARD, CONTACT WHEEL
1
12
802-4
CONTACT WHEEL
1
13
923-4
BRACKET, TRACKING
1
14
707c
SHAFT, BEARING
1
15
701F
WHEEL, IDLER CIR-CLIP
2
16
907-4
WHEEL, IDLER, WITH BEARING
1
17
942B
DOOR, GUARD
1
18
742E
HINGE
1
19
942-4A
GUARD, SAFETY, PAINTED
1
20
742H
GROMMET, SAFETY GUARD DOOR
1
21
742L
LATCH, SAFETY GUARD DOOR
1
22
942C-4
STANDOFF, DOOR
1
23
922
LOCK, KNOB, TRACKING
1
24
18
WASHER, 960-516, AN
1
25
924
SUPPORT, BACKUP
1
26
921-4
KNOB, TRACKING ASSY
1
27
2
BOLT, 5/16-18x1 1/2 HEX HEAD
4
28
4
WASHER, 5/16 SAE ZINC PLTD
10
29
1-0003
3/8-16 x 1 1/4 HEX HEAD BOLT
2
30
17
WASHER, 960-616, AN
6
31
5-0014
WASHER, LOCK 3/8, INTERNAL STAR
2
32
40
WASHER, SAE, 3/8
1
33
39
NUT, 3/8-24, JAM, ESNA, NTE
4
34
6
1/4-20 x 1 1/2 FH SOC
3
35
904-4A
PLATEN
1
36
904B
BRACKET, PLATEN
1
37
5
WASHER, 1/4 AN
10
38
30
1/4-20x1 SHCS
6
39
1-0019
BOLT, 5/16-18x1 1/2 HEX HEAD
6
40
31
1/4-20x1 1/4 SHCS
3
41
14
NUT, 10-24, KEP
3
42
23
NUT, 6-32, KEP, PLTD
3
43
2-0023
SCREW, 10-24 X .625 ALLEN HEAD
3
44
5-0036
WASHER, #8, LOCK, INTERNAL
3
45
4-0013
NUT, KEP, 1/4-20
2
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
54
737A
KNOB, REAR TENSION ARM
1
55
737B
BUTTON
1
56
26
PIN, 3/32 x 3/8, ROLL PLTED
1
57
737D
SPRING, BUTTON
1
58
937C
STRIP
1
59
737E
NIPPLE, PIPE
1
60
737F
PAWL
1
61
34
SCREW, 1/4-20 X 1, FH PHILLIPS
1
62
738
SPRING, BELT TENSION
1
63
940
SUPPORT, IDLER WHEEL
1
64
27
SCREW, DRIVE, #8 X 5/8
1
65
28
SCREW, DRIVE, #2 x 1/4
1
66
736
RACHET
1
67
15
WASHER, 5/16 LOCK, SPLIT
2
68
9
SCREW, 10-24x1/2 BH, BLK OXIDE
5
69
937G
HANDLE
1
70
25
SCREW, SET 5/16-18 x 3/8
1
71
3
NUT, 1/4-20 JAM, PLTD
2
72
935
SUPPORT, REAR WHEEL
1
73
939
GUIDE, SPRING
1
74
21
WASHER, 1/2 ID
1
75
20
NUT, NYLOK JAM, 1/2-20
1
76
24
SCREW, 6-32 x 1/2, MACH
3
77
42
WASHER, SAE, 3/8
4
78
5-0027
1
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
46
29
SCREW, 10-32 X 1/2 BH
1
47
5-0032
WASHER, 1/4, LOCK, SPLIT, PLTD
1
48
951
BELT, V DRIVE
2
49
1
BOLT, 5/16-18x1, HH, GRD 5, PLTD
1
50
4-0009
NUT, 3/8-16, JAM, PLTD
1
51
2-0001
1/4-20x1 1/4 SHCS
2
52
726
WASHER, SPRING FLANGE
1
53
727
NUT, 5/8-18 RH, JAM, BRT PLT
1
1 1/2 HP
CHANGES
TO
2-3HP
BUSHINGS
730
931
949
5/8"
950
7/8"
725
933
947
5/8"
429
951
2(qty)
