FOR CUSTOMER SERVICE CALL

1-800-783-8353

Teledex, LLC

6311 San Ignacio Avenue

San Jose, CA

95119

Telephone: (408) 363-3100

Fax:

(408) 363-3136

email:

[email protected]

Internet:

www.teledex.com

Part Number 606-3510-00A

TELEDEX BTX3500/3510 DIAGRAM

RING VOLUME

Adjusts the ringer volume

to Low or High setting

.

DATA PORT

HANDSET VOLUME KEY

Changes handset volume by
pressing repeatedly.

MESSAGE WAITING LIGHT

Signals that a message is waiting for retrieval.
See your system administrator for instructions
on retrieving messages.

FLASH KEY

For programming of FLASH duration.
See instructions for programming details.

STORE KEY*

Key used when storing information in the
AUTO DIAL key

HANDSET HOLDER

Used to temporarily hold the handset,

without hanging up the telephone,

when telephone is wall mounted.

HEARING AID

COMPATIBLE

HANDSET

HANDSET JACK

Modular jack for connecting handset to base.

DIAL KEYS (DTMF PAD)

For dialing phone numbers, and entering
numbers to be stored in auto dial keys.

AUTO DIAL KEYS 1-5*

For easy, one-touch dialing of guest services or
PBX features. Programmed during installation.

REDIAL KEY*

To automatically redial
last number dialed

DESK/WALL CONVERTER TAB

*Applies to the BTX3510 only.
