background image

712S

Cabinet Color

All Black

Panel

TFT Active Matrix LCD
VIS: 17" ( 43.2cm ), Diagonal

Pixel Pitch

0.264mm x 0.264mm

Display Area

338mm x 270mm

Brightness

300 cd/m2 (typ)

Contrast Ratio

600:1 (typ)

Response Time

5ms (typ)

Viewing Angle

Horizontal: 170 Degrees (CR>5)
Vertical: 170 Degrees (CR>5)

Compatibility

VESA, SXGA, XGA,SVGA,VGA
Mac® Equipped With VGA Port

Scanning Frequency

Horizontal: 30K~80KHz
Vertical: 55~75 Hz

Pixel Frequency

135MHz

Maximum Resolution
Recommended Resolution
Resolutions Supported

1280x1024@75Hz
1280x1024@60Hz
720x400@70Hz, 640x480@60/75Hz, 800x600@60/75Hz,
1024x768@60/70/75Hz, 1280x1024@60/75Hz

Color

16M

Signal Input

Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative

Connectors

RGB Signal: 15-pin D-sub
(3-Pin Plug CEE22)

Power Source

Universal 100~240VAC, 50/60Hz (Internal Power Supply)

Power Consumption

37Watts ( Max. )

Plug & Play

DDC2B

EPA ENERGY STAR®

Yes

User Control

Auto Adjust Key, Brightness, Contrast, Power Button, MENU

OSD Function

Contrast,Brightness, Focus, Clock, H/V Position, Auto Config,
Language, Information, OSD Setup, Warm/Cool Color, User Color
temperature, sRGB, Reset, Exit

OSD Languages

English, French, Spanish, Portuguese, German, Italian, Chinese,
Russian

Regulations

FCC, cULus, Woks for Windows Vista Logo, Rohs

Other Features

VESA Wall Mount Compliant*, Kensington Security Slot

Dimensions (WxHxD mm)

Monitor: 386.08x330.2x210.82; Carton 433x399x133

Dimensions (WxHxD inches)

Monitor: 15.2x13.0x8.3 ; Carton: 17.0x15.7x5.2

Monitor Dimensions w/o Base (WxHxD)

15.2x13.0x2.7

Weight

9.35 lbs (4.25kgs) Net
11.55 lbs (5.25 kgs) Gross

Loading Qty w/pallet

20' = 1195 pcs.; 40' Std = 2295 pcs.

UPC Code

685417009688

Note: Specifications are subject to change without notice. *Wall mount arm & bracket not included.
