Specifications A
57
Table A-2. Supplemental Characteristics (continued)
Parameter Agilent 6814B Agilent 6834B Agilent 6843A
INH/FLT Characteristics
Maximum Ratings: 16.5 Vdc between INH terminals; FLT terminals; and from INH
terminals to chassis ground
INH Terminals: Iol = 1.25 mA max.
Vol = 0.5 Vmax.
FLT Terminals: Vil = 0.8 V max.
Vih = 2 V min.
tw = 100
µ
s min.
td = 4 ms typical
Saveable Data (nonvolatile)
Instrument States: 16 (0 to 15)
User-defined waveforms: 12 (with 1024 data points in each)
List Data: 1 to 100 points (for each list function)
GPIB Interface Capabilities
Language: SCPI, Elgar 9012 PIP
Interface: AH1, C0, DC1, DT1, E2, LE1, PP0, RL1, SH1, SR1, TE6
Programming Time: 10 ms
Recommended Calibration Interval: 1 year
Regulatory Compliance
Listed to: UL 3111-1
Certified to: CSA 22.2 No. 1010-1
Conforms to: IEC 1010
RFI Suppression
Complies with: CISPR-11, Group 1, Class A
Dimensions
Height (add 12.7 mm or 0.5 in. for feet) 262.6 mm (10.3 in.)
Width: 430.8 mm (16.96 in.)
Depth: 602 mm (23.7 in.)
Net Weight: 79.5 kg (175 lb) 87.7 kg (193 lb) 87.7 kg (193 lb)
Shipping Weight: 119.1 kg (626 lb) 127.3 kg (280 lb) 127.3 kg (280 lb)
