Kenwood CAW2190-24-RT User Manual
Kenwood Radio

2
3
1
4
© 12/2008 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Compatible with these Kenwood double DIN devices
Kenwood Navigation
Installation Manual
Double DIN Kit
Rubber-Touch: CAW 2190-24-RT
• Mercedes SLK-Class (R171) 2005
Installation Manual Double DIN Kit 2190-24-RT
7. Place the mounting frame at the
dashboard. Fix it with the original
screws.
Place the metal frame into the
mounting frame.
Double DIN Set contents
• (1) Metal Frame
• (2) Installation Kit
• (3) Mounting frame
• (4) Facia Plate
8. Connect all required circuit points
to the Kenwood head unit and
push it into the metal frame until
it snaps in.
Place the facia plate
Reinstall everything in reverse
order to finish installation.
(sample photo)
