Installation Manual Double DIN Kit CAW 2170-06-RT Mazda 6 (Type GH) 2009->
1. Remove the air vent unit above
the OEM head unit
4. Remove the cup holder unit
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
2. Remove the gear shift cover
3. Remove the side panels
at the left and right side
5. Remove the silver panel of
the center console
6. Remove the air condition
control unit
7. Remove the screws at the
bottom of the OEM head unit.
( there are also two screws
at the top, see step 7 )
