Kenwood CAW1270-01 User Manual
Page 2

2-Din 12.301270-01
Gently remove the air ventilation shaft
with a plastic wedge.
Place the 2-Din metal bracket.
Remove the torx screws at the location of
the arrows and remove the radio.
Place the head unit and connect all the
wiring.
Connect all of the needed wiring harnesses and check all the connections carefully.
1
2
3
4
2-DIN CAW-1270-01
