Installation Manual
Double DIN Kit CAW 2190-25-RT
• Mercedes SL-Class (R230) 2004
Installation Manual Double DIN Kit CAW 2190-25-RT
6. Place the facia plate on the dash-
board.
Place the metal frame into the
facia plate.
Double DIN Set contents
• (1) Metal Frame
• (2) Installation Kit • (3) Facia Plate
• (4) Trim Frame
7. Connect all required circuit points
to the Kenwood head unit and
and push it into the metal frame
until it snaps in. Place the trim
frame.
Reinstall everything in reverse
order to finish installation.
