Kenwood TK-2180E User Manual
Page 18
11
e
e
e
e
e Power switch/ Volume control
Turn clockwise to switch ON the transceiver. Rotate to
adjust the volume. Turn counterclockwise fully to switch
OFF the transceiver.
r
r
r
r
r Transmit/ Busy/ Call indicator
This LED lights red during transmission, green while
receiving a call, and orange when receiving an encoded
call (i.e. 5-tone, DTMF signaling, etc.).
t
t
t
t
t Auxiliary (orange) key
Press to activate its programmable function {page 14}.
y
y
y
y
y Safety Catch
Lock this catch to avoid accidentally pressing the release
latch and removing the battery pack {page 7}.
u
u
u
u
u Release Latch
Press the release latch to unlock and remove the battery
pack {page 7}.
i
i
i
i
i Side 1 key
Press to activate its programmable function {page 14}.
o
o
o
o
o PTT (Push-To-Talk) switch
Press this switch, then speak into the microphone to call a
station.
!0
!0
!0
!0
!0 Side 2 key
Press to activate its programmable function {page 14}.
!1
!1
!1
!1
!1 S, A,
Press to activate their programmable functions {page 14}.
!2
!2
!2
!2
!2 DTMF keypad
Press the keys on the keypad to make DTMF calls
{page 30} or to activate their programmable functions
{page 14}.
!3
!3
!3
!3
!3 Universal connector
Connect a speaker/ microphone or headset here {page 9}.
Otherwise, keep the supplied cap in place.
