P H Y S I C A L S P E C I F I C A T I O N S ( F O R A L L M O D U L E S )
Dimensions
• Height: 1.3 cm (0.5 in.)
• Width: 17.1 cm (6.7 in.)
• Depth: 17.8 cm (7.0 in.)
• Weight: 0.45 kg (1.0 lb)
Environmental Specifications
• Operating temperature: 5 C to 40 C
(41 F to 104 F)
• Relative humidity: 15% to 85%
(non-condensing)
• Altitude: 3,048 m (10,000 ft)
Regulatory Agency Standards
• Safety: UL 60950-1, CAN 60950-1,
EN 60950-1, CE Mark
• EMC: EN 55022
• EMI: FCC Part 15, Class A; EN 55022
SONET/SDH MDA Part Numbers
Table 4 provides an ordering summary for the Alcatel-Lucent SR SONET/SDH MDAs.
Table 4. SONET/SDH MDA Ordering Information for the Alcatel-Lucent SR Family
PART NUMBER MDA TYPE PLATFORM NOTES
3HE00032AA 8-port OC-3/STM-1 7750 SR/7710 SR 8-port SONET/SDH OC-3c/STM-1c MDA, accepts up to eight (8)
OC-3/STM-1 SFP Optics Modules
3HE00033AA 16-port OC-3c/STM-1c 7750 SR 16-port SONET/SDH OC-3c/STM-1c MDA, accepts up to sixteen (16)
OC-3/STM-1 SFP Optics Modules
3HE00037AA 8-port OC-12c/STM-4c 7750 SR 8-port SONET/SDH OC-12c/STM-4c MDA, each port can operate as
OC-12c/OC-3c or STM-4c/STM-1c, accepts up to eight (8) OC-12/STM-4,
OC-3/STM-1 SFP Optics Modules
3HE00038AA 16-port OC-12c/STM-4c 7750 SR 16-port SONET/SDH OC-12c/STM-4c MDA, each port can operate as
OC-12c/OC-3c or STM-4c/STM-1c, accepts up to sixteen (16)
OC-12/STM-4, OC-3/STM-1 SFP Optics Modules
3HE00043AA 2-port OC-48c/STM-16c 7750 SR 2-port SONET/SDH OC-48c/STM-16c MDA, accepts up to two (2)
OC-48/STM-16 SFP Optics Modules
3HE00044AA 4-port OC-48c/STM-16c 7750 SR 4-port SONET/SDH OC-48c/STM-16c MDA, accepts up to four (4)
OC-48/STM-16 SFP Optics Modules
3HE00048AA OC-192c/STM-64c 7750 SR 1-port SONET/SDH OC-192c/STM-64c MDA with SR-1 / I-64.1 optics,
1310 nm, Simplex SC Connector
3HE00049AA OC-192c/STM-64c 7750 SR 1-port SONET/SDH OC-192c/STM-64c MDA with IR-2 / S-64.2 optics,
1550 nm, Simplex SC Connector
3HE00709AA OC-192c/STM-64c 7750 SR 1-port SONET/SDH OC-192c/STM-64c MDA with LR-2 / L-64.2 optics,
1550 nm, Simplex SC Connector
