GAS “HOT SURFACE IGNITION” (HSI) SYSTEM
MODEL TRITON 2465 (ADC Part No. 128974) 50/60 Hz TYPE ONLY
PRODUCT INFORMATION and TROUBLESHOOTING GUIDE
NOTE: Failure to read and follow ALL instructions and information included in this
manual carefully before operating and/or servicing this system, COULD
CAUSE PERSONAL INJURY and/or PROPERTY DAMAGE.
IMPORTANT: We have tried to make this manual as complete as possible and
hope you will find it useful. However, since the time of this
printing, some information contained herein may have been up-
dated.
ADC RESERVES THE RIGHT TO MAKE CHANGES FROM TIME TO TIME,
WITHOUT NOTICE or OBLIGATION IN PRICES, SPECIFICATIONS, COLORS,
and MATERIALS, and TO CHANGE or DISCONTINUE MODELS or PARTS.
Table of Contents
Failure To Light - LOCKOUT ..................................................................... 2
Flame Failure Reignition ............................................................................... 3
HSI System Operation ............................................................................................. 5
HSI System Operation (Flow Chart) ........................................................................ 6
Normal Operation (summary) .................................................................................. 7
HSI Troubleshooting Terms (definitions) ................................................................... 8
Troubleshooting/System Diagnosis (detailed) ............................................................ 9
