Figure 1:
Typical amplifier
panel and controls
for Model T70.1
PBM. Your amplifier
may differ from
this illustration.
Important Note: If you are using a surround receiver/processor that includes its own filtered subwoofer
output we recommend that you set the crossover switch on the T70.1 PBM to Bypass.
● Two line inputs, two line outputs
The outputs allow daisy chaining of multiple subwoofers, or can act as a return path back to the
processor.
● Two high level inputs, two high level outputs
These let you connect the subwoofer to your amplifier using the amplifier’s speaker outputs. The
speaker outputs may be connected to the left and right front satellite speakers.
