KDAR Company
3
Specifications/Features & Benefits/Package Contents
Table 1
Features & Benefits
1. Peak Output—6500 Watts
2. Rated Output—5500 Watts
3. Single Phase 60 Hz
4. On/Off Switch
5. Voltmeter
6. Low Oil Shut Off
7. Separate Ground Connector
8. Generator/Motor on Rubber Mounts
9. 8” Solid Wheels
10. Fold Down Pull Handle
11. 12 Volt DC Circuit, 8.3 Amps, Battery Charger
12. All Outlets Circuit Protected
13. 2 x 120V AC, 20 Amp Grounded (5-20R)
14. Dual 120/240V AC, 21A Twist Lock (L14-30)
15. Dual 120/240V AC, 21A Twist Lock (L5-30)
16. 13 HP Engine rated at 3600 RPM, 418cc
17. Spark Arrestor Muffler
18. TCI Ignition
19. Gas Tank, 6.6 Gal, with Input Fuel Filter
20. Fuel Shut Off with Internal Fuel Filter
21. Noise Level of 67 dB(A) @ 24 Ft.
22. Run Time of 8 Hours at 50% Load
Package Contents
1. Generator
2. Operator’s Manual
3. Warranty Card
4. Spark Plug Wrench
5. Screw Driver
6. Wheels (2)
7. Axles (2)
8. Axle Washers (2)
9. Cotter Pins (4)
10. Rubber Foot (2)
11. Handle
12. Handle Pivot Bracket
13. Handle Pivot Bracket Support
14. Handle Catch
15. Front Foot Support
16. Bolts—8M x 25M (2)
17. Bolts—8M x 16M (4)
18. Bolts 8M x 40M (2)
19. Bolt 8M x 58M
20. Bolt 6M x 60M
21. Nuts 8M (9)
22. Nut 6M
Generator Ratings
Engine
Type
Brush Single Phase
Engine Type & Displacement OHV Single Cylinder 389cc
Voltage Regulate
AVR
Maximum Output HP/RPM
13/3600
AC Rated Output
5.5kW/5500 Watts
Oil Capacity
1.16 Qt. (1.1 Liter)
AC Maximum Output 6.5kW/6500 Watts
Low Oil Shut Down
Standard
AC Voltage
120V/240V
Fuel Type
Gasoline
AC Frequency
60 Hz
Fuel Capacity
6.6 Gallons
120 VAC Amperage Rated 45.8/Max 54.2
Run Time @ 1/2 Load
9 Hours
240 VAC Amperage Rated 23/Max 27.1
Operating Noise Leve
67 dB(A) @ 24 Ft.
DC Voltage
12V Battery Charger
Outlets
DC Amperage
8.3 Amps
1 x 12V DC 8.3 Amp Connector
Dimensions & Weight
2 x 120V 20 Amp Grounded
Dimensions (inches) 27.6 x 21.3 x 23.3
1 x Dual AC 120/240V 21 Amp Twist Lock, 4 Prong (L14-30)
Weight
211.6 Lbs
1 x 120V 21 Amp Twist Lock, 3 Prong (L5-30)
