Specifications/Features & Benefits/Package Contents
Generator Ratings Engine
Type Brush Single Phase Engine Type & Displacement OHV Single Cylinder 418cc
Voltage Regulate AVR Maximum Output HP/RPM 15/3600
AC Rated Output 6.5kW/6500 Watts Oil Capacity 1.16 Qt. (1.1 Liter)
AC Maximum Output 8.0kW/8000 Watts Low Oil Shut Down Standard
AC Voltage 120V/240V Fuel Type Gasoline
AC Frequency 60 Hz Fuel Capacity 6.6 Gallons
120 VAC Amperage Rated 54.3/Max 66.7 Run Time @ 1/2 Load 8 Hours
240 VAC Amperage Rated 27.1/Max 33.3 Operating Noise Level 67 dB(A) @ 24 Ft.
DC Voltage 12V Battery Charger Only Outlets
DC Amperage 8.3 Amps 1 x 12V DC 8.3 Amp Connector, Battery Charger Only
Dimensions & Weight 2 x 120V 20 Amp Grounded (5-20R)
Dimensions (inches) 31.1 x 22.0 x 32.3 1 x Dual AC 120/240V 27 Amp Twist Lock, 4 Prong (L14-30)
Weight 211.6 Lbs 1 x 120V 27 Amp Twist Lock, 3 Prong (L5-30)
Table 1
Features & Benefits
1. Peak Output—8000 Watts
2. Rated Output—6500 Watts
3. Single Phase 60 Hz
4. On/Off Switch
5. Voltmeter
6. Low Oil Shut Off
7. Separate Ground Connector
8. Generator/Motor on Rubber Mounts
9. 8” Solid Wheels
10. Fold Down Pull Handle
11. 12 Volt DC Circuit, 8.3 Amps, Circuit Protected
12. All Outlets Circuit Protected
13. 2 x 120V AC, 20 Amp Grounded (5-20R)
14. Dual 120/240V AC, 27A Twist Lock (L14-30)
15. 120V AC, 27A Twist Lock (L5-30)
16. 15 HP Engine rated at 3600 RPM, 418cc
17. Spark Arrestor Muffler
18. Electronic Key Start
19. Battery Included
20. TCI Ignition
21. Gas Tank, 6.6 Gal, with Input Fuel Filter
22. Fuel Shut Off with Internal Fuel Filter
23. Noise Level of 67 dB(A) @ 24 Ft.
24. Run Time of 8 Hours at 50% Load
Package Contents
1. Generator
2. Operator’s Manual
3. Warranty Card
4. Keys (2)
5. Spark Plug Wrench
6. Screw Driver
7. Wheels (2)
8. Axles (2)
9. Axle Washers (2)
10. Cotter Pins (4)
11. Rubber Foot (2)
12. Handle 13. Handle Pivot Bracket
14. Handle Pivot Bracket Support
15. Handle Catch
16. Front Foot Support
17. Bolts—8M x 25M (2)
18. Bolts—8M x 16M (4)
19. Bolts 8M x 45M (2)
20. Bolt 8M x 58M
21. Bolt 6M x 60M
22. Nuts 8M (9)
23. Nut 6M
24. Battery (12V/17AH)
