A90/P90

4

A90/P90

5

E

n

g

li

sh

Standby power

For remote standby operation, the amplifier’s control power
supply is kept powered up all the time the unit is connected to
the mains supply. The front panel power switch powers down all
other circuitry. Power consumption in this mode is less than 2W.
This means that even though the power switch is off, it may be
possible to hear a slight residual hum coming from the mains
transformer inside the amplifier. This is perfectly normal. If the
unit is to be left unused for an extended period, we recommend
that it is disconnected from the mains supply by switching it off
at the wall socket.

Connecting to other equipment

The use of high quality interconnect cables to and from your
amplifier is recommended to ensure the best sound quality.
Sockets marked

L

(and

R

) on your amplifier should only be

connected to sockets marked

L

(and

R

) on other equipment. All

the line inputs have the same sensitivity and may be used with
equipment other than that labelled, if needed.
TAPE1/RECORD OUT

8

– Connect these output sockets

to the input sockets of your cassette deck (usually labelled

RECORD

).

TAPE1/PLAY IN

9

– Connect these input sockets to the

output sockets of your cassette deck (usually labelled

PLAY

). If

you do not have a cassette deck you can use this input for other
(line level) equipment, such as a CD player, tuner, VCR, etc., but
not a turntable.
VCR/TAPE2 RECORD OUT

bk

– These output sockets can

be connected to the input sockets of VCR/second recorder
(usually labelled

RECORD

).

VCR/TAPE2 PLAY IN

bl

– Connect these input sockets

to the output sockets of your VCR/second recorder (usually
labelled

PLAY

). Alternatively, you can use this input for other

(line level) equipment such as a CD player, tuner, etc., but not a
turntable.
DVD

bm

– Connect this input to the audio outputs of a DVD

player.
AV

bn

– Connect this input to audiovisual equipment such as a

VCR, laserdisc player, satellite or Nicam tuner.
TUNER

bo

– Connect this input to the audio outputs of your

radio tuner.
CD

bp

– Connect this input to the audio outputs of your CD

player or DAC (digital to analogue converter).
AUX

bq

– Connect this input to the audio outputs of any unit

with a line level output, e.g. tape deck, tuner etc.

NOTE: The AUX inputs must not be used if the phono module
is fitted. When this is fitted AUX becomes an output carrying
the equalised phono signal at line level.

PHONO

br

– As standard, phono inputs are blanked. Phono

inputs are provided on a separate plug-in module which your
Arcam dealer or distributor can supply and fit. This module
is compatible with most high output moving coil and moving
magnet cartridges (MM) and low output moving coil cartridges
(MC). MM or MC is selected via the

MM/MC

back panel switch.

Phono earth terminal – For connecting your turntable earth
lead (if fitted). Note that this terminal must not be used as a
safety earth.

TRIG OUT

AND

REMOTE IN

3

(12V in and out) – These

connections are intended for use in multi-room installations.

TRIG OUT

– This output provides a 12V signal whenever the

unit is switched on (i.e., not off or in standby). This signal
can be used to switch on automatically power amplifiers
(or other equipment) connected to the A90, as they will
come on when the A90 is activated. This is useful if the
power amplifier is remote from the A90, or otherwise
difficult to access.

REMOTE IN

– This allows remote control signals to be received

by the A90 if the remote sensor is covered (or otherwise
not ‘visible’ to the remote control). An external sensor
is used to receive the signals from the remote control,
which are then fed to the A90 (into this input) using a
suitable cable. Remote control signals acceptable to the
A90 must be in modulated RC5 format, with a voltage
level of between 5V and 15V.

Note that in normal use there is no need to make any
connections to these sockets. If you would like to make use of
these features, please contact your dealer for more advice on
how to make the connections and on what type of cable to use.

Pre/power amplifier connections

PWR IN

5

– To use your integrated amplifier as a power

amplifier, connect the output of your pre-amplifier to the

PWR IN

sockets.
Press in the

PRE/PWR

switch

7

on the rear panel to

select separate pre-amp/power amp mode. Under these
circumstances your A90 has exactly the same specification and
performance as a power amplifier (see page 10).

PRE OUT

6

– To use your integrated amplifier as a pre-

amplifier, connect the

PRE OUT

sockets to the input sockets

of your power amplifier. With a power amplifier of the correct
gain (e.g. the P90 power amplifier) you can bi-amplify (‘bi-amp’)
suitable loudspeakers, giving significant improvements in sound
quality (see page 12).
