Electrix MOFX - Manual (Page 10)

English
21
5. SPECIFICATIONS
Actual measurements are subject to change
Function Transmitted Recognized Remarks
Basic Channel Selectable 1-16 1-16
Mode Default X Mode 3
Messages X X
Note Number X X
Velocity Note ON X X
Note Off X X
After Touch X X
Pitch Bender 0 0 Flange depth
Control Change
Program Change X X
System Exclusive O O
System Common Song Position X X
Song Select X X
Tune Request X X
System Real Time Clock X O
Commands X X
Aux Messages Local On/Off X X
All notes Off X X
Active Sensing X X
System Reset X X
Notes:
1. When flange syncro is “on” the values represent division settings: 0-17=8:1, 18- 35=4:1, 36-53=2:1, 54-71=1:1, 72-
89=1:2, 90-107=1:4, 108-127=1:8
2. 0=all, 1=High, 2=Mid, 3=Low, 4= High+Low 5=Mid+Low, 6=Mid+High
3. When auto-pan/tremolo syncro is “on” the values represent division settings: 0-17=8:1, 18-35=4:1, 36-53=2:1, 54-
71=1:1, 72-89=1:2, 90-107=1:4, 108-127=1:8
4. When Delay syncro is “on” the values represent division settings: 0-17=1:8, 18-35=1:4, 36-53=1:2, 54-71=1:1, 72-
89=1.5:1, 89-107=2:1, 108-127=4:1
5. 0=Tap Tempo 1= MIDI Clock 2= automaticly switches to MIDI clock upon receiving MIDI Clock Start message (FO)
Mode 1: OMNI ON, POLY
Mode 2: OMNI ON, MONO 0: YES
Mode 3: OMNI OFF POLY Mode 4: OMNI OFF MONO X: NO
MIDI IMPLEMENTATION CHART
24
25
26
27
29
30
32
33
34
35
37
38
39
40
41
42
43
45
46
47
48
49
50
51
52
53
54
55
67 O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O Distortion to FX, 0-63 (off), 64-127 (on)
Distortion engage, 0-63 (off), 64-127 (on)
Distortion level, 0-127
Distortion “drive”, 0-127
Flange engage, 0-63 (off), 64-127 (on)
Flange level, 0-127
Flange speed, 0-127, note 1
Flange Feedback, 0-127
Flange band assign, note 2
Flange band Synchro, 0-63 (off), 64-127 (on)
Tremolo engage, 0-63 (off), 64-127 (on)
Tremolo level, 0-127
Tremolo depth, 0-127
Tremolo speed, 0-127 note 3
Tremolo Auto-pan 0-63 (off), 64-127 (on)
Tremolo band assign, note 2
Tremolo syncro, 0-63 (off), 64-127 (on)
Delay engage, 0-63 (off), 64-127 (on)
Delay level, 0-127
Delay feedback, 0-127
Delay time, 0-127 note 4
Delay ping-pong, 0-63 (off), 64-127 (on)
Delay band assign, note 2
Delay syncro, 0-63 (off), 64-127 (on)
Tap Tempo Mode, note 5
Dry, 0=Thru, 1=Kill, 2=Auto
Bypass, 0-63 (off), 64-127 (on)
Dump Front Panel Request
Tap Tempo, 127 Trigger
INPUT SOURCE SOURCE SOURCE
Connectors: 1/4” TRS RCA(phono) RCA(line)
(balanced)
Max Input Level: +16.0 dBu -24.5 dBV +16.0dBu
Impedance: 66K
Ω
48.5K
Ω
66K
Ω
OUTPUT EFFECT OUTPUT
OUTPUTS
Connectors:
1/4”TRS bal RCA
Impedance: 450
Ω
1K0
Ω
Max Output Level: +16.0 dBu +16.0 dBu
PERFORMANCE 1/4” PHONO RCA
Dynamic Range: >90db >78db <85db
THD: <0.04% <0.05% <0.05%
Frequency Response: 10Hz-14.3kHz 10Hz-14.3kHz 10Hz-14.3kHz
A to D Conversion: 18bit/44.100 kHz Sampling rate
D to A Conversion: 18bit/44.100 kHz Sampling rate
POWER CONSUMPTION VOLTAGE FREQUENCY FUSE
30 watts 100 V 50/60 Hz 250mA 250V Slow blow
120 V 50/60 Hz
230 V 50/60 Hz 125mA 250V “T”
240 V 50/60 Hz
4. MIDI
4.3
