Model 42-403

05/10

10

Item

Part Name

Model

5-025

Model

5-050

Model

5-075

Model

5-150

Qty

75

Relief valve spring

893

893

893

893

1

76

Ball valve ¼” dia.

918

918

918

918

1

77

Relief valve seat

891

891

891

891

1

78

Valve cap nut

2236

2236

2236

2236

1

79

Relief valve adjusting screw

2237

2237

2237

2237

1

80

Ball retainer

892

892

892

892

1

81

Cylinder

5726

4101

2213

4197

1

82

Check valve spring

579

579

579

579

1

83

Gauge

71270

71271

71272

71273

1

84A Control panel - Old Style 3-1/2” hole

27618

27618

27618

27618

1

Control panel - New Style 4” hole

80744

80744

80744

80744

1

84B Label for panel

27620

27620

27620

27620

1

85

Spring pins

1/8”

dia.

x 9/16”

28524

28524

28524

28524

3

86

Control handle ball

27879

27879

27879

27879

1

87

No.

10-24 x 3”

Flat head slotted screw

300248

300248

300248

300248

4

88

No.

10-24 x 3/8

” soc. head cap screw.

43396

43396

43396

43396

2

89

Control handle mounting bracket

27622

27622

27622

27622

1

90

Control rod

27621

27621

27621

27669

1

91

Control handle

27433

27433

27433

27433

1

92

Neoprene washer

2248

2248

2248

2248

4

93

¾” pipe nipple x 8”

44205

44205

44205

44205

1

94

Vent tube

6038

6038

6038

6038

1

95

Retaining plate

7359

6513

6514

6474

1

96

5/8” flat washers

49927

49927

49927

49927

7

97

5/8”-11 hex nut

43917

43917

43917

43917

7

98

5/8” lockwasher

43648

43648

43648

43648

7

99

Rear roller bracket

9472

9472

9472

4204

1

100 ¾”-10 x 3” Soc set screw

43616

43616

43616

43616

3

101 3/8”-16 x 1” hex cap screw

43328

43328

43328

43328

4

102 Roller screw

1297A

1297A

1297A

1297A

3

103 Flanged roller

2244

2244

2244

2244

3

104 Bearing

6023

6023

6023

6023

3

105 Front roller bracket

9473

9473

9473

4205

1

106 Motor – 2 HP, 220/440 volt 3-phase

29744

29744

29744

29744

1

106A Bolts, motor mounting (5/16-18 x ½”)

43313

43313

43313

43313

4

107A Coupling (with Spider)

28498

28498

28498

28498

1

107B Spider only

301337

301337

301337

301337

1

108 Gasket

6516

6517

6518

6519

1

109 3/8”-16x1” hex cap screw

43328

43328

43328

43328

8

110 3/8” lockwasher

43645

43645

43645

43645

8

111 Pump and motor base

25915

25915

25915

27668

1

112 Pump

950101

950101

950101

950101

1

113 ½” lockwasher

43647

43647

43647

43647

4

114 ½”-12x1-½” hex head cap screw

43469

43469

43469

43469

4

115 1/8” Allen pipe plug

589

589

589

589

1

116 Pump support

25916

25916

25916

25916

1

116A Bolts, pump support (5/16-18 x ¾”)

43314

43314

43314

43314

4

117 Tube fitting

1251

1251

1251

1251

1

118 Tube assembly

705921

705921

705921

705921

1

119 Tube elbow

1252

1252

1252

1252

2

120 Tube assembly

701160

701160

701160

701161

1
