70H & 75H Press
8/02
6
Item
Qty
Description
Part No.
39
1
1
Gauge
Bushing
71267
81384
40 1
Gauge
Extension
731
41 4
Roller
592
42
2
4
Roller Shaft
Retaining Ring
733
43975
43 1
Dake
Name
Plate
81002
44
1
Air Vent Tube
632
45 1
Handwheel
10631
46 2
V-Block
336
47 2
Table
Plate
702
48 6
Table
Pins
569
49 2
Table
Channel
706945
50 1
Frame
only
706943
51 2
Base
Angle
566
52
2
Fitting, 3/8 NPT, 37
°
1251
53
2
2
Fitting Nut
Fitting Sleeve
46614
51454
54
1
Tube Assembly (53 & 54)
700121
55 1
Handle
218
56 2
Pulley
727
2
Pulley
Bolt
43361
2
Pulley
Nut
43916
2
Pulley
Lockwasher
43647
57 1
Vent
Tube
67761
58
2
Fitting, Tube, Poly-Tite
71413
59
17’
Cable (sold in feet)
45953
60 4
Cable
Clamps
991
61
4
4
4
4
Table Spacer
Bolt, Hex Head 5/8”
Hex Nut 5/8”
Lock Washer 5/8”
86488
79983
43917
43648
TABLE HOIST
Item
Qty
Description
Part
No.
62
63
1
Hand Crank Assembly
701653
64 1
Worm
Shaft
384
65
2
Retaining Ring
27437
66 1
Worm
Key
47364
67 1
Worm
385
68 1
Hoist
Frame
725
69
1
Hex Cap Screw
43335
70 1
Hex
Nut
43912
71 1
Drum
Shaft
724
72 1
Drum
Key
737
73 1
Worm
Gear
736
74 1
Cable
Drum
723
75
1
Retaining Ring
43992
Complete Table Hoist Assembly
700112
FRAME ASSEMBLY
