have been made, it is advisable to set the lockout switch to ON to avoid accidental
alteration of any of the settings.
S21-8
SET Key Lockout
OFF
SET key not locked out
ON
SET key can only be used to clear
alarms
7.6 Camera Termination
An 8-way DIL switch (referenced as S1) is provided within the switcher (near the
rear) to allow camera inputs to be individually terminated or unterminated.
Switch Camera
Input
OFF ON
S1-1
1
Not Terminated
75 Ohm Termination
S1-2
2
Not Terminated
75 Ohm Termination
S1-3
3
Not Terminated
75 Ohm Termination
S1-4
4
Not Terminated
75 Ohm Termination
S1-5
5
Not Terminated
75 Ohm Termination
S1-6
6
Not Terminated
75 Ohm Termination
S1-7
7
Not Terminated
75 Ohm Termination
S1-8
8
Not Terminated
75 Ohm Termination
