Vi-R2000 Series
Videoswitch Page 4 Mdr601a.doc
1.1.1 Vi-R2001 Keyboard Control
Key Function(s)
1, 2, 3, 4, 5, 6,
7, 8, 9, 0 Live: 1 – 8 Select full screen cameras
Mouse Emulator Mode
Press and hold the 0 key for 1 second to bring up right-click menu
Up, Down,
Left, Right Standard Mode: Live: Select cameras Menu Mode: Move from field to field
Mouse Emulator: Move mouse pointer around screen
SEL Standard Mode
Live: Start/stop auto sequence
Menu: Select menu option
Mouse Emulator Mode Select (Left mouse click)
ESC Escape from current menu level. Also used as an ALT key for extra functions.
MOUSE Press and hold for 1 second to turn mouse emulator on or off. When mouse emulator in ON,
pointer appears on screen. Do select the mouse emulator if an external mouse is connected to
the MOUSE USB port.
PLAY Press and hold for 1 second to enter PLAY mode. If password is enabled you will need to log-in
before entering PLAY mode.
PTZ Press and hold for 1 second to enter PTZ dome mode If password is enabled you will need to
log-in and enter PTZ mode via menu.
MENU Press and hold for 1 second to enter MENU. If password is enabled you will need to log-in before
entering MENU mode.
EDIT Press and hold for 1 second to enter edit mode when a numeric entry is required in for password
or menu.
F1 Not used
F2 Press and hold for 1 second to step through tabs in some menu screens.
SCREEN Step through multi-screens. Use arrow keys to select cameras 1-4 or 5-8 in quad mode.
Note:
Some keys have different functions depending on current mode of the DVR
