Agri-Fab AgriFab Push Spreader 45-0462/45-0471 User Manual
Page 19
19
rePaIr ParTs FOr 45-0462, 45-0471 130 LB. Push sPreader
reF QTY ParT NO
desCrIPTION
1
1
41084
Hopper
2
1
41316
Hopper Cover (45-0471)
3
1
41097
Tube, Hopper Support LH
4
1
41096
Tube, Hopper Support RH
5
1
42004
Tube, Stand
6
1
42006
Tube, Handle
7
1
42115
Grip, Foam (45-0471 only)
8
1
42012
Bail, Flow Control
9
2
40880
Wheel
10
2
49870
Bolt, Hex 1/4-20 x 2-1/2
11
7
1509-69
Bolt, Hex 1/4-20 x 1-3/4
12
2
43648
Bolt, Hex 1/4-20 x 1-1/2
13
1
43012
Bolt, Hex 1/4-20 x 3/4 (45-0471)
14
12
47189
Nut, Hex 1/4-20 Nylock (45-0462)
13
47189
Nut, Hex 1/4-20 Nylock (45-0471)
15
4
R19212016 Washer, .6562 x 1.25 x .0598
16
2
48857
Spacer, .64 ID x .84 OD x 1.00
17
2
40315
Bearing, Flat Sided Flange
18
2
48499B
Hub Cap
19
1
66866
Flow Control (incl. items 20 - 24)
20
1
41093
Cable, Flow Control (ref 66866)
21
1
41087
Dial, Flow Control (ref 66866)
22
1
41088
Housing, Flow Control (ref 66866)
23
1
42007
Spring, Flow Control (ref 66866)
24
1
41092
Shuttle, Flow Control (ref 66866)
25
1
1509-90
Bolt, Hex 1/4-20 x 1-1/4
26
4
1543-69
Washer, Nylon .3281 x .75
27
5
43088
Washer, 1/4 Std .312 x .734
28
1
26711
Shaft, Spreader
29
2
47212
Housing, Large Gear
30
3
44125
Washer, .625 x 1.0 x .03
31
1
47204
Yoke, Large
reF QTY ParT NO
desCrIPTION
32
1
43659
Pin, Spring 3/16 x 1
33
1
47209
Gear, Large
34
1
47205
Gear, Small
35
1
26710
Shaft, Axle Spreader
36
1
41090
Plate, Flow
37
2
42011
Spring, Flow Plate
38
1
41196
7/32" Conduit Clip
39
1
44285
Bushing, Hopper Bottom Black
40
1
49898
Clip, Hairpin 5/8
41
1
46855
Pin, Cotter 3/16" x 2"
42
1
48934
Hairpin, Agitator
43
2
46055
Pin, Spring 1/8 x 1
44
1
04367
Spreader Impeller
45
2
49897
Clip, Hairpin 7/8
46
1
43010
Pin, Cotter 1/8 x 1-1/4
47
1
41086
Side Deflector (45-0471)
48
1
41089
Clamp, Push Rod (45-0471)
49
1
41094
Push Rod (45-0471)
50
1
41099
Deflector Rod (45-0471)
51
1
42186
Connecting Rod (45-0471)
52
1
42188
Eye Clamp (45-0471)
53
1
47317
Grip, 2" (45-0471)
54
2
HA23740 Screw, 1/4-20 Tapping (45-0471)
55
1
141
Washer, .378 x 1.25 x .061 (45-0471)
56
2
48402
Plug, 1/4" (Christmas Tree)
57
1
27170
Cross Brace
58
1
43177
Lock Washer,1/4"
59
1
23625
Spacer
60
1
741-0475 Bushing, 3/8" Plastic
61
2
47856
Screw, 5/16 x 3/4"
62
2
43086
Lock Washer, 5/16"
1
41178
Owner's Manual
