S E R V I C E
ASC-2E & ASC-4E Electric Convection Ovens - Electronic Control • 25
Part numbers and drawings are subject to change without notice.
C O N T R O L A S S E M B L Y - A S C - 4 E
5
2
4
1
6
7
8
14
13
12
16
10
9
3
11
15
ITEM
DESCRIPTION
PART NO. QTY ITEM
DESCRIPTION
PART NO.
QTY
1
HEAT ELEMENTS, REAR
208V
eL-34128
1
7
MOTOR RELAY
RL-33558
2
240V
eL-34125
1
8
RELAY
RL-33930
2
480V
eL-34345
1
9
POWER SUPPLY
BA-33554
1
2
HEAT ELEMENTS, MIDDLE
208V
eL-34127
1
10
BLOCK, TERMINAL
BK-3597
1
240V
eL-34146
1
11
BLOCK, MODULAR
BK-34684
1
480V
eL-34346
1
12
FUSE HOLDER
FU-34771
1
3
HEAT ELEMENTS, FRONT
208V
eL-34126
1
13
CONTACTOR
CN-3731
1
240V
eL-34129
1
14
BLOCK, 2 TERMINAL, PORCELAIN
BK-33546
1
480V
eL-34347
1
15
PANEL OVERLAY
PE-26977
1
4
FAN, BOX 35
CFm, 230V, 50-60H
z
FA-3974
1
16
SWITCH, FAN, HI/LOW
SW-34101
1
5
BUSHING, STRAIGHT, STRAIN RELIEF
BU-3964
1
17*
BEEPER
BP-3567
1
6
SENSOR
SN-33541
1
18*
FUSE, 15 AMP
FU-34772
2
*Not Shown
