The information in this manual furnished for information use only, is subject to change without notice,
is not to be construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
©2004 ATN Corp. All right reserved.
2
APPLICATION
The PS-14 Multi-use Night Vision monocular is one of the most versatile night vision devices
available. This unit can be handheld, head-mounted for hands free usage, it is camera/ cam-
corder adaptable, and can be made into a 4x or 6.5x bi-ocular. This unit can also be weapon-
mounted. The intergrated IR illuminator enhances the ability of the user to read maps and oper-
ate in confined, zero light areas. The PS14 is available with several image intensifier options to
meet a wide array of specification requirements.
The PS-14 night vision monocular is a complex opticoelectronic system for individual use. The
device consists of the objective lens assembly, eyepiece and the body. The body contains an
image intensifier tube assembly with an integrated high voltage power source and the battery
housing.
Objective lens protective cover is intended to protect the objective lens from dust and
scratches. It also will act as a daylight filter, allowing you to test the scope in daylight or other
bright light situations. The pinhole in the center of the protective cover allows the user to check
the operation ability of the device in daylight conditions.
NOTE: Do not test the scope in daylight conditions even with the daylight filter/lens cap on for
more than ten (10) minutes.
• High Quality light intensifier tube
• Super fast lens system provides the user
with a clear and sharp image
• Built-in Infra Red illuminator lets you see
even in total darkness
• Interchangeble lenses for different mag-
nification
• Adjustable Flip-up headmount for hands
free use
• Automatic brightness control for high-light
protection
• IR-on and Low Battery indicators
• Rugged and versatile design
• Single switch knob operation
• Camera/camcorder-adaptable
• Helmet-mountable
• Weapon -mountable
• Flexible carrying case
• Uses one AA battery
• Waterproof 20 meters for 1 hour
• Two-year factory warranty
SPECIFICATIONS
Magnification .......................................................... 1X (optional 3X, 5X)
Detection range ...................................................... 200(Gen.2) or 350(Gen.3) m/y
Recognition range .................................................. 150(Gen.2) or 300(Gen.3) m/y
Lens System ........................................................... 24 mm; F1:1.2
Field of view ............................................................ 40°
Range of Focus....................................................... 0.25m to 
Power Supply.......................................................... 1.5 volt AA size battery
Battery Life ............................................................. 60 hours (20 hours with IR illuminator)
Operating Temp. ..................................................... -30°F to +110°F
Waterproof. ............................................................. 20 m for 1 hour
Dimensions............................................................. 151x80x55 mm (6.7” x 2.5” x 4”)
Weight..................................................................... 0.32kg (0.7 lb)
FEATURES
