Specification – Abocom AP900 User Manual
Page 2
Specification
Standards
IEEE 802.11g
IEEE 802.11b
IEEE 802.11
IEEE 802.3u 100Base-TX Fast Ethernet
ANSI/IEEE 802.3 N-way Auto-Negotiation
Channels &
Frequency
♦
USA (FCC): 2.412GHz ~ 2.462GHz (Ch1-11)
♦ Europe (CE): 2.412GHz ~2.472GHz (Ch1-13)
Data Rate (wireless)
W/ automatic fallback
54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, and 1Mbps
Security
64-bit, 128-bit WEP encryption
MAC Address filter
802.1x
WPA (Wi-Fi Protected Access)
Antenna
2dbi
Button
One Factory Reset button
LED indicators
Power
Status always On / Blinking: while upgrading firmware
Ethernet On: Link / Off: Not Link / Blinking: Active
On: 100Mbps / Off : 10 Mbps
On: Full duplex / Off: half duplex
Wireless (bridge mode) On: Associated / Off : not Associated
Wireless (bridge mode) On: Ready / Off : Not ready; Blinking : try to connect.
Wireless Blinking : Active
Management
Web-Based configuration and management
Power
5.0VDC, 1.5A input.
Physical Dimension
127 x 91.1 x 24.7(mm) (Width x Depth x Height)
Weight
190g
Temperature
Operating: 0~50 ℃
Storing: 0~70 ℃
Humidity
95% maximum (non-condensing)
Safety & Emission
FCC
CE
