Ema linear actuator – Power Jacks EMA Actuators User Manual
Page 11
EMA Linear Actuator
Tel: +44 (0) 1358 285100 email: [email protected]
web: www.powerjacks.com
11
6.1
EMA Clutch General Assembly
6.2
EMA Clutch Settings
Actuator
Rating
Lead
Type
Torque
Clutch Lever Force
(kg
(mm)
-
(Nm)
lbs
kg
250
3
T
7.8
7
3
250
5
B
4.9
4
2
250
6
T
15.6
14
6
250
10
B
9.8
9
4
250
12
T
31.2
28
13
250
20
B
19.5
17
8
250
25
B
24.4
22
10
500
3
T
15.6
14
6
500
5
B
9.8
9
4
500
6
T
31.2
28
13
500
10
B
19.5
17
8
500
12
T
62.4
55
25
500
20
B
39
35
16
500
25
B
48.8
43
20
1000
5
B
19.5
17
8
Type:
T
-
Trapezoidal
B
-
Ball Screw
Item Number
Description
1
2
3
4
5
6
7
8
Inner Tube (ram)
Distance Piece
Clutch Housing
Tab Washer
Lock Nut
Clutch Spindle
Conical Rings
Thrust Bearing
