The supported enclosure interface:
(Mini-SAS)
(eSATA)
RocketStor 6328 connection diagram:
6.2 Connecting the RocketStor 6328 (RS6328)
Steps:
a. Connect the RS6328 to the storage enclosure using an industry standard Mini-SAS cable. Power on the
storage enclosure.
b. Connect the Power Adapter to the RS6328.
c. Connect the RS6328 to the host system using a Thunderbolt™ cable.
