KEY PART
NO. DESCRIPTION
1. Vent Cap w/Screen
2. Adaptor, Flue Mounting
3. 5
′ ABS Schedule 40
Vent Pipe
4. 90° ABS Schedule 40
Elbow
5. Vent/Blower Adapter
6. Blower
7. Flue Adaptor Gasket
(6 ″ x 10.102″)
8. Blower Gasket
9. Venting; Manual
Reset Switch
10. Vent Hood Assembly
11. Rubber Gasket – Wiring
12. T&P Valve
13. Dip Tube
14. Anode Rod
15. Wiring Harness
16. Drain Pan
17. Hot Surface Ignition
Assembly
18. Orifice (Natural)
Standard
18. Orifice (L.P.)
Standard
18. Orifice (Nat.)
High Altitude
18. Orifice (L.P.)
High Altitude
Repair Parts (cont’d)
Now that you have purchased this Water Heater, should a need ever exist for repair parts or service, simply contact the com-
pany it was purchased from or the manufacturer listed on the model rating plate on the water heater.
Be sure to provide all pertinent facts when you call or visit.
Selling prices will be furnished on request or parts will be shipped at prevailing price and you will be billed accordingly.
The model number of your Gas Water Heater will be found on the model rating plate located above the gas control valve.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
MODEL NUMBER (TYPE GAS) NATURAL OR PROPANE (L.P.)
SERIAL NUMBER PART DESCRIPTION
PART NUMBER
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
35
KEY PART
NO. DESCRIPTION
19. Burner Assembly (Nat.)
19. Burner Assembly (L.P.)
20. Inner Door
21. Drain Valve
22. Manifold (Natural)
22. Manifold (L.P.)
23. Right Access Door
w/Gasket
24. Left Access Door
w/Gasket
25A. Access Door Clips (2)
25B. Jacket/Access
Door Clips (8)
26. Pressure Switch (Air) Cover
27. Gas Thermostat (Nat.)
27. Gas Thermostat (L.P.)
28. Power Cord
29. Mounting Bracket
30. On/Off Switch
31. Pressure Switch (Air)
32. Flue Baffle Assembly
33. Baffle Adaptor
Collar Assembly
34. Water Heater Stand
35. Optional (Deluxe)
Horizontal Vent Kit
36. 4 to 5 pin adapter
