30
Y1-03-0222 Rev. C
APPENDIX D - DATA POWER CABLE INFORMATION
Class B A2-07-0196-1
DATA POWER
CABLE
J1 J2
Description DB15 DB9 Wire Type Color AWG CABLE #
12V + 1 Tinned Copper RED 18 CABLE1
12V - 9 Tinned Copper BLACK 18 CABLE1
RS422 TX A 2 Tinned Copper ORANGE 22-24 CABLE 2
RS422 RX A 3 Tinned Copper YELLOW 22-24 CABLE 2
RS422 TX B 10 Tinned Copper BLACK 22-24 CABLE 2
RS422 RX B 11 Tinned Copper WHITE 22-24 CABLE 2
SW1GND 15 Tinned Copper BLACK 22-24 CABLE 3
SW1 Switch 8 Tinned Copper PURPLE 22-24 CABLE 3
RS232 TX 12 2 Tinned Copper RED 22-24 CABLE 4
RS232 RX 13 3 Tinned Copper BLUE 22-24 CABLE 4
GND 14 5 Tinned Copper BLACK 22-24 CABLE 4
Note: Connectors J1 and J2 have shielded jackets with ground connection to metal shell of connector.
Cable 2 and Cable 3 have staggered length clipped conductors to prevent shorting and are capped with heat
shrink.
