SPRAYING SYSTEMS 43L-AL SPRAY GUN

PART #

ITEM

BRASS

ALUMINUM

DESCRIPTION

CP1325

CP1325-AL

CAP, BRASS, or ALUMINUM

D-**

ORIFICE DISC, HARDENED STAINLESS STEEL

CP4743-NY

GASKET, NYLON

CP10566

CP10566-AL

NOZZLE HOUSING, BRASS or ALUMINUM

10565

10565-AL

SEAT PLUG ASSEMBLY - BRASS or ALUMINUM

CP10571-2-NYB

CP10571-3-NYB

GUIDE VANE, NYLON

CP10571-AL

GUIDE VANE, ALUMINUM

CP45195-NYB

CP45196-NYB

GASKET, NYLON (2 REQUIRED)

CP19238-416SS

CP19238- 416SS

STEM, TYPE 416 STAINLESS STEEL

CP6604

CP6604-AL

TUBING, BRASS or ALUMINUM

CP6942

CP6942-AL

INLET BODY, BRASS or ALUMINUM

CP6601-302SS

PACKING WASHER, TYPE 302 STAINLESS STEEL

CP6602-LEA

PACKING LEATHER ( 3 REQUIRED)

CP6602-TEF

PACKING TEFLON (3 REQUIRED)

CP19237

CP19237-AL

PACKING SCREW, BRASS or ALUMINUM

CP6599

CP6599-IZP

LOCKNUT, BRASS, or STEEL ZINC PLATED

CP9641-INP

STEM NUT, STEEL NICKEL PLATED

CP6595-SS

TRIGGER STOP SPRING, SS

CP7991-SS

WASHER,

CP6597-INP

TRIGGER GUIDE, STEEL NICKEL PLATED

CP6591-SS

SPRING STUD, STAINLESS STEEL

CP6589-IZP

STOP ADJUSTMENT NUT, STEEL ZINC PLATED

CP6594-SS

SPRING FOR STOP ADJUSTMENT NUT, SS

CP6588-IZP

SPRING SCREW, STEEL ZINC PLATED

CP6592-302SS

SPRING GUIDE WASHER, TYPE 302 SS

CP6593-1-SS

MAIN SPRING, SS for MODEL 43L

CP6593-2-SS

MAIN SPRING, SS for MODEL 43H

CP14477-1-AL

HANDLE BODY, ALUMINUM

CP7623-IZP

RIVET, STEEL NICKEL PLATED

CP6509-INP

TRIGGER, STEEL NICKEL PLATED

CP6510-INP

TRIGGER STOP, STEEL NICKEL PLATED

CP11757-SS

SCREW, STAINLESS STEEL

CP13798-INP

TRIGGER GUARD, STEEL NICKEL PLATED

GUNJET No. AA43L - BRASS, FOR PRESSURE UP TO 200 psi

GUNJET No. AA43L-AL - ALUMINUM, FOR PRESSURE UP TO 200 psi

GUNJET No. AA43H - BRASS, FOR PRESSURES FROM 200 to 800psi

GUNJET No. AA43H-AL - ALUMINUM FOR PRESSURES FROM 200 to 800psi

PK-AB43-KIT SPARE PARTS KIT (includes all items marked)

PK-AB43-AL-KIT SPARE PARTS KIT (includes all items marked)
