Ag Spray Equipment BASPOTSPRAYERK - Manual

Warranty/Parts/Service
Products are warranted for one year from date of purchase
against manufacturer or workmanship defects.
Commercial users have a 90 day warranty.
Your authorized dealer is the best source of replacement
parts and service. To obtain prompt, efficient service, always
remember to give the following information...
- Correct Part Description and/or part number.
- Model number/Serial number of your sprayer.
Part descriptions and part numbers can be obtained from the
illustrated parts list section(s) of this manual.
Whenever you need parts or repair service, contact your
distributor/dealer first. For warranty work, always take your
original sales slip, or other evidence of purchase date, to
your distributor/dealer.
Pump is shown but
not included in this assembly.
Nozzle features a multi-patented round covered orifice •
design which improves spray pattern & distribution.
No small orifices or slots to get plugged up. •
1/4" (MNPT) inlet threads ( Male National Pipe Thread) •
Nozzle produces a very even, large droplet spray •
pattern.
Superior wear & chemical resistance. •
Eliminates cumbersome boom 'arms'. •
Eliminate most 'normal' boom maintenance. •
Spray easily around obstacles & over uneven terrain •
All full pattern spray nozzles were tested at a height of •
36 inches. (recommended operating height is between
18 & 48 inches.) These nozzles are designed to
provide a full left-hand to right-hand spray pattern
from a single centrally mounted nozzle.
Features/Benefits
Model: BASPOTSPRAYERK (5302060)
(Bolt-On Boomless Nozzle Assembly for Spot Sprayers with 'Top-Mounted' pumps)
Owner's Manual
Thank you for purchasing this product. The purpose of
this manual is to assist you in operating and
maintaining your boomless nozzle setup. Please read
it carefully, as it furnishes information which will help
you achieve years of trouble-free operation.
Form No. 2002 [5008306 (11/10)] Printed in the U.S.A.
www.agspray.com
1100 New Industry Lane
Hopkinsville, KY 42240
P: 800-637-7172
F: 270-885-7392
1563 S. Oates Street
Dothan, AL 36301
P: 800-227-4098
F: 334-673-1974
104 Eastman Street
Greenwood, MS 38930
P: 800-844-4524
F: 662-455-4442
