"A"
Troubleshooting a 1.0 g.p.m. Pump:
this should restore most of your prime.
break them free with some WD-40 or something similar and
other. If these 2 pieces are 'stuck' together, you will need to
freely, and they both need to spin INDEPENDENT of each
- Both the counterweight and the bearing need to spin
bearing and counterweight.
- Unscrew (2) screws "S". This will allow you to inspect the
Periodically take the screen at this location out and clean it.
solution in the tank will be away from this inlet location.
may need to tilt the tank backwards a little bit so any
tank should be empty while performing this, otherwise you
this screen. (see exploded view later in this manual) The
tank. You will need to unscrew the knurled nut to access
- Check line strainer (screen) at the inlet location, at the
Pump runs, but does not prime:
know that your lead wire assembly needs to be replaced.
volts to the pump. If your pump runs after doing this, you will
them together. This will insure you are getting the full 12
screwed to the rocker switch, off of the switch and twist
screws, and 'hot-wire' it together. Take the (2) wires that are
the lead wire assembly (#5274443) with the (2) phillips head
Another thing you can try is to take apart the switch box on
when you do this, you know you will need to replace your
pressure switch cap before doing this) If your pump runs
over and touch terminal "B". (You will need to remove the
of the spade terminal of the pressure switch, and cross it
If none of the above will work, try pulling wire terminal "A" off
- Insure a tight connection at the battery clips.
- Make sure you 12 volt source (battery) is fully charged.
- Make sure BOTH on/off switches are in the 'on' position (-).
replace with new fuse. (5 Amp mini-blade fuse...#5157204)
- Check inline fuse on the wires on the pump. If blown,
Pump will NOT run:
pressure switch.
Pump Assembly w/Pressure Switch
Pressure Switch w/Diaphragm
Qty
5095202
5157204
5275531
5157201
5157207
2
4.1
3.1
3
Item
No
1
1
1
1
1
Number
Part
1
5 Amp Mini Fuse
Rocker Switch
Pump Foot (Pkg. of 4)
Description
"B"
Bearing
"S"
List
Price
3.99
37.95
23.95
6.99
4.99
3.1
4.1
1
screw (Factory Preset)
Pressure adjustment
3
counterweight
"Half-Moon"
2
1
(12 Volt, 4 Amp, 1.0 gpm, 35 psi)
#5275702 Pump
Page 2
After Spraying
After use, fill the sprayer tank part way with water. Start the
sprayer, and allow the clear water to be pumped through
the plumbing system and out through the spray nozzles.
Refill the tank about half full with plain water and use a
chemical neutralizer, such as 'Nutra-Sol', or equivalent,
and repeat cleaning instructions above. A mix of water and
some good dish detergent, would be a sufficient
alternative.
Flush the entire sprayer with the neutralizing/cleaning
agent, then flush out one more time with plain water.
Follow the chemical manufacturer's disposal instructions of
all wash or rinsing water.
For the boom, (if applicable) remove the tips and screens
from the nozzle assemblies. Wash these items out
thoroughly. Blow the orifice clean and dry. If the orifice
remains clogged, clean it with a fine bristle (NOT WIRE)
brush, or with a toothpick. Do not damage the orifice.
Water rinse and dry the tips before storing.
WARNING: Some chemicals will damage the pump
valves if allowed to soak untreated for a length of time!
ALWAYS flush the pump as instructed after each use.
Winter Storage
Drain all water out of your sprayer, paying special
attention to the pump, handgun, and valve(s). These items
are especially prone to damage from chemicals and
freezing weather.
The sprayer should be winterized before storage by
pumping a solution of RV antifreeze through the entire
plumbing system. This antifreeze solution should remain in
the plumbing system during the winter months. When
spring time comes and you are preparing your sprayer for
the spray season, rinse the entire plumbing system out,
clearing the lines of the antifreeze solution. Proper care
and maintenance will prolong the life of your sprayer.
